U s e e x i s t i n g b o l t s
Fig. 1
Installation:
This bracket will install under the radio box using the bolts
that hold the radio box to the rear deck.
1. Remove the radio box and place the bracket onto the radio
box bolts (Figs 1 & 2).
2. Remount radio box, securing the lighthead bracket.
3. Mount the lighthead to the bracket using the supplied
flange and metal screws (Fig. 3).
4. Extend the lighthead wires to your power source and refer
to the lighthead manual for instructions.
©2004 Whelen Engineering Company
Inc. Form No.13933C (030409)
ENGINEERING COMPANY INC.
51 Winthrop Road,
Chester, Connecticut 06412-0684
Phone: (860) 526-9504
Fax: (860) 526-4078
U s e e x i s t i n g b o l t s
Fig. 1
Installation:
This bracket will install under the radio box using the bolts
that hold the radio box to the rear deck.
1. Remove the radio box and place the bracket onto the radio
box bolts (Figs 1 & 2).
2. Remount radio box, securing the lighthead bracket.
3. Mount the lighthead to the bracket using the supplied
flange and metal screws (Fig. 3).
4. Extend the lighthead wires to your power source and refer
to the lighthead manual for instructions.
©2004 Whelen Engineering Company
Inc. Form No.13933C (030409)
®
