TCi V1k series Installation Manual

Motor protection filter

Advertisement

Quick Links

Warnings and Cautions
Warning
Dangerous Voltage Warning: warns of
situations in which a high voltage can
cause injury and/or equipment damage.
The text next to this symbol describes
ways to avoid danger.
Warning
General Warning: warns of situations
that can cause physical injury and/
or equipment damage by means other
!
than electrical. The text next to this
symbol describes ways to avoid the
danger.
General Safety Instructions
Warning
Be sure to read, understand, and follow
!
all safety instructions.
Warning
Only qualified electricians should
carry out all electrical installation and
!
maintenance work on V1k drive output
filters.
Warning
All wiring must be in accordance with
the National Electrical Code (NEC)
!
and/or any other codes that apply to
the installation site.
Warning
Disconnect all power before working
on the equipment. Do not attempt any
work on a powered V1k output filter.
Warning
The V1k, VFD, motor, and other
connected equipment must be properly
grounded.
Warning
The VFD terminals and connected
cables are at a dangerously high voltage
when power is applied to the VFD,
regardless of motor operation.
All electrical connections must be
re-torqued annually.
Field Wiring
Field Wiring Connection Terminals
Compression type terminals are provided for all line
wiring connections. The wire size capacity ranges and
tightening torque for the power terminals are listed in the
table.
Input and Output Motor Power
V1k Model
Numbers
Wire Size
V1k2A to V1k12A
12 - 14
V1k16A
4 - 12
V1k18A to V1k21A
4 - 10
V1k25A to V1k27A
4 - 8
V1k35A
6 - 8
V1k45A
6
V1k55A
1 - 4
V1k80A
1 - 3
V1k110A
2/0 - 1/0
V1k130A
2/0
V1k160A
250 MCM - 3/0
V1k200A
two 2/0 - 1
V1k250A
two 2/0
V1k305A
two 350 MCM - 3/0
V1k362A
two 350 MCM - 4/0
V1k420A
two 600 MCM - 300
V1k480A
two 600 MCM - 350
V1k600A
two 600 MCM - 500 MCM
V1k750A
three 600 MCM - 400 MCM
See www.transcoil.com for dimensions tables. Please contact
TCI Technical Support or your TCI distributor for application
information regarding the use of V1k output filters on the
output side of the VFD.
TCI, LLC
W132 N10611 Grant Drive
Germantown, Wisconsin 53022
Ph: 800-TCI-8282
www.transcoil.com
Torque
(in.-lb.)
10
20
20
20
30
30
35
35
Installation
50
50
375
Guide
50
50
375
375
500
500
500
500
W132 N10611 Grant Drive
Germantown, Wisconsin 53022
Revision G
V1k
TCI, LLC
Ph: 800-TCI-8282
www.transcoil.com
Part # 25316
April 13, 2018
