- Page 1 Instruction Manual for Operation & Maintenance BigSprinkler.com | 15250 Sunshine Rd. Yukon, OK. 73099 | 1-855-805-7901...
- Page 2 Safety is the main priority and failure to follow these instructions may cause serious injury. Neither ReelGreen nor BigSprinkler.com are to be responsible for machine failure or personal injury if these Caution •...
-
Page 3: Identification Data
Identification Data The identification plate includes the model and serial number for your machine. Machine Controls & Components Shut-off Valve Latch Drum Gear (under cover) Shut off valve (pull valve-do not turn) Grease Zerk for Inlet Seals (Open small valve to add grease.) Water Connection Point (garden hose) Shut-off Bar... - Page 4 Conditions For Machine Operation The RG25 is designed for clean water suitable for irrigation. The machine is not designed for water that includes large pieces of debris or slurry/wastewater conditions. Start-Up Procedure/Operation 1) Push the machine to the desired location. Position the machine with the sprinkler cart facing the direction to be irrigated.
- Page 5 Start-Up Procedure/Operation Continued **Important: Always pull cart out straight and tighten loose wraps before start up! ALWAYS PULL TUBE KEEP WRAPS TIGHT! OUT STRAIGHT! 5) Re-engage the turbine assembly by loosening the black knob again and sliding the turbine bracket back into place as shown by white arrow, so that the drive gears mesh.
- Page 6 Start-Up Procedure/Operation Continued 8) Turn on the water source to the RG25. The sprinkler equipped with the RG25 can be set to water a full circle pattern or any part of a circle. It is generally recommended to water a half circle pattern behind the cart, away from the direction of travel.
-
Page 7: Parts Diagrams
Parts Diagrams SHUT-OFF/SPEED CONTROL ASSY. FRAME/CHASSIS SPRINKLER CART... - Page 8 Parts Diagrams DRIVE SYSTEM DRUM...
-
Page 9: Troubleshooting
Drum Gear: Grease drum gear every 100 hours. Turbine Seals: Replace turbine seals every 500 hours or once a season. Consult your dealer for more information. Performance Chart Reel Green RG25 Performance Chart RUN TIME (HRS) INLET MAX WIDTH 80% ADJ MAX LENGTH 0.8”... - Page 10 4. Disconnect yellow turbine entry hose as shown by the blue arrow. 5. Drain guncart by removing plug located on the underneath side of the cart as shown in the image below. Guncart drain location on RG25 Options RG25 Air Blow Out Fitting •...
- Page 11 BigSprinkler.com, will (at BigSprinkler.com’s option) repair or provide purchaser replacement parts F.O.B. Yukon, OK. As follows: All components of new ReelGreen system for 1 year from original equipment invoice, free of charge. BigSprinkler.com will repair or provide replacement polyethylene tube for any tube BigSprinkler.com determines has failed, due to defects in workmanship or materials for 3 years...
