For current product specifications, please to go
www.griffin-stands.com and type the model number
into the search bar. Locate the product listing to view
the current factory specifications.
Performance Issue, Uneven or Unstable-
sure all nuts and bolts are tight on the product. If they
are, then loosen all nuts and bolts 1 full turn counter-
clockwise, then go back and tighten each bolt only ½
turn tight. Then do a final tighten turn for another ½
turn tight. Next, Make sure there are not any missing
nuts or bolts. Third, ensure all parts on the product
are not broken or defective. Finally, Re-read the
assembly
instructions
or
watch
demonstration video to ensure you have correctly
assembled or are using the product properly with
factory specifications.
Missing Parts-
The pictures, videos and images
shown in this manual might have changed style or
count due to the product being redesigned. So in rare
cases the part may no longer be included or of a
different style. However, if you think you are missing
a part that is necessary to the assembly and use of
your product, then first carefully double check all
packaging for any parts you think are missing. Some
parts might be hiding in the packaging or loose in an
inner box.
www.Griffin-Stands.com
Thank you for purchasing the Griffin Remote Hi-Hat
Stand. Your product comes with a 1 year factory
warranty from purchase date. Please read all
assembly instructions prior to assembling your new
cart. Pictures that may aid in assembly can be found
Make
by going to www.griffin-stands.com and typing H40R
into the search bar.
Griffin™ stands and accessories are manufactured
in several innovative factories responsible for
developing products that address the newest
needs and trends of the current market. We take
pride in the Griffin™ brand and endeavor to be on
the forefront of the musical stands and musical
and lighting accessories market.
the
product
Griffin | 11408 Hwy 64 W, Tyler, TX 75704 |
info@griffin-stands.com | www.Griffin-
www.Griffin-Stands.com
Stands.com
U s e r M a n u a l
M o d e l # H 4 0 R
Remote Hi -Hat
Stand
www.Griffin-Stands.com
