BENRO Classic Series Operating Instructions

Reversible Center Column
(FIGURES 7 & 8)
Your Tripod has the ability to reverse the
Center Column for close-up photography,
copy work and for difficult to reach objects.
To reverse the Center Column, unscrew
the Retractable Weight Hook located
on the bottom of the Center Column.
Loosen the Center Column Locking Knob
and pull the Center Column out. Insert
the Center Column through the bottom
with the Mounting Plate upside-down and
retighten the Center Column Locking Knob
securely. The Center Column has an anti-
twist groove, be sure to line-up the groove
with the key before inserting the Column
back into the Main Casting.
NOTE: Do not reverse the Center Column
when a camera or equipment is mounted.
User Adjustments
(FIGURES 9 & 10)
Leg Angle Hinge Pivot tension can be
adjusted using the 4mm Allen Key. Flip Lock
Lever tension is adjusted using the 3mm
Allen Key plus the special Six-sided Socket
Wrench built into the plastic clip which
comes attached to one of the tripod legs.
75 Virginia Road
North White Plains, NY 10603
T 914.347.3300
F 914.347.3309
info@BenroUSA.com
BenroUSA.com
USER NOTICE
• Do not exceed the maximum specified
load capacity (see specifications at
www.BenroUSA.com).
• Always ensure that Leg and Head Locks
are tightly engaged before mounting any
gear on your Tripod.
• Always clean and dry any Tripod after it
has been exposed to wet, dusty, sandy
or salty conditions. Your Tripod is not
recommended for use in salt water. If
required, clean tripod using a mild soap
solution applied with a soft cloth, rinse
with fresh water and dry with soft towel.
Remove any dust, dirt or sand from all Leg
Locks, Leg Sections and all moving parts.
• Do not leave any Tripod in the sun for
prolonged periods and avoid high
temperature exposure.
• Avoid leaving any Tripod or Monopod
unattended in areas where people could
trip over the gear and get hurt.
• Remove camera, lens, and all gear from
any tripod when transporting.
• For your safety, don't let your Benro
gear come in contact with any electrical
power source.
Specifications and design are subject
to change without notice.

Operating Instructions

Thank you for making Benro your choice for professional photographic
equipment. Your Benro gear is manufactured to provide years of
dependable service. In order to obtain optimum satisfaction and
performance, we suggest that you carefully read these instructions.
