Specification
Model
MTX1000DIR
Pick up Element
1/3" SONY 1.3Megapixel CMOS Sensor
Effective Picture Elements
1305(H) X1049(V)
(H×V)
Horizontal Resolution
1000TVL
Minimum lllumination
0.01Lux/F1.2
S/N Ratio
More than 50dB
Scanning System
2:1 interlace
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC:1/60s~1/100,000s,PAL:1/50s~1/100,000s
Gama Characteristic
IR Distance
20 Meters (with ￠5X24 Unit Infrared LED)
IR Status
Under 10 Lux by CDS
IR Power On
CDS AUTO Control
Video Output
1Vpp,75 Ω
Auto Gain Control
Power/Current
DC12V(+/-10%)/ 350mA
Lens
Board Lens 3.6mm/F2.0
Dimension (mm)
￠94 x 69(H)
Weight (g)
Storage Temperature
-30~ +60℃ RH95% MAX
Operating Temperature
-10~ +50℃ RH95% MAX
Packing List
No
Name
Model
1.
Vandalproof IR Dome Color Camera
MTX1000DIR
2.
User Guide
MTX1000DIR
0.45
Auto
400
Number
1
1
www.generalsecurity.ro
MTX1000DIR Color Camera
Vandalproof IR Dome Color Camera
Notes:
Before providing power for the
camera, please read this User Guide in
detail!
Do not attempt to disassemble the camera.
If the camera can not work, please contact
local franchiser or our company.
