Installation instruction
ULTRA TWIN HIC-35
6 316 08 66 35
= W
ULTRA TWIN HIC-35 SP10
6 316 08 66 35 SP10
= W
ULTRA TWIN HIC-35 WFL46
6 316 08 66 35 WFL46
= W
163mm
6"-7/16
Ø84mm
Ø3"-5/16
360°
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Application
Ceiling surface mounted
Installation to a standard 4" octagonal box with optional coverplate installation
or Mud kit installation
For indoor use only
Color Finish
W - White (RAL 9003)
Light source
1 x T4.5 39W
Ø84mm
Ø3"-5/16
Product description
Powder coated aluminum housing
Input voltage: 120V /50-60Hz
Lampholder: G8.5
Suitable for damp locations
Protected against solid objects greater than 12mm
Weight: 2,9lbs 1,3kg
Accessories not supplied (option)
6 207 02 02
6 204 00 109
= ANO / ALU / A / W / B
NORTH AMERICAN EDITION
MUD KIT 1
COVERPLATE R 109
ULTRA TWIN HIC-35
IP20
Last Update 25/03/2013
1
Advertisement
Table of Contents
Related Manuals for Delta Light ULTRA TWIN HIC-35
Summary of Contents for Delta Light ULTRA TWIN HIC-35
- Page 1 ULTRA TWIN HIC-35 Installation instruction ULTRA TWIN HIC-35 6 316 08 66 35 ULTRA TWIN HIC-35 SP10 6 316 08 66 35 SP10 ULTRA TWIN HIC-35 WFL46 6 316 08 66 35 WFL46 Application Ceiling surface mounted Installation to a standard 4” octagonal box with optional coverplate installation...
- Page 2 ULTRA TWIN HIC-35 Installation instruction INSTALLATION LUMINAIRE Accessories SAVE! MOUNTING TEMPLATE CABLE ENTRY 120° MUD KIT INSTALLATION COVERPLATE INSTALLATION MAX 2x 14-18AWG 50L/STR WHITE WHITE BLANC BLANC BLACK BLACK NOIR NOIR Coverplate GREEN GREEN VERT VERT 6 204 00 109 1/2”...
- Page 3 ULTRA TWIN HIC-35 Installation instruction INSTALLATION LUMINAIRE 90° NORTH AMERICAN EDITION HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca Last Update 04/07/2012...
