  • Page 2 500W HAMMER DRILL INSTRUCTION MANUAL PDI500GE ORIGINAL INSTRUCTIONS...

  • Page 3: General Power Tool Safety Warnings

    ORIGINAL INSTRUCTIONS GENERAL POWER TOOL outdoors, use an extension cord suitable for outdoor use. Use of a cord SAFETY WARNINGS suitable for outdoor use reduces the risk WARNING: Read all safety of electric shock. warnings and all instructions. f) If operating a power tool in a damp Failure to follow the warnings and location is unavoidable, use a instructions may result in electric shock, fire...
  • Page 4 ORIGINAL INSTRUCTIONS dust collection can reduce dust-related identical replacement parts. This will hazards. ensure that the safety of the power tool is maintained. 4) POWER TOOL USE AND CARE a) Do not force the power tool. Use HAND DRILL SAFETY the correct power tool for your INSTRUCTIONS application.

  • Page 5: Component List

    ORIGINAL INSTRUCTIONS COMPONENT LIST 1. Depth gauge 7. Auxiliary handle 2. Chuck 8. Locking screw for handle collar 3. Switch lock button 9. Locking screw for depth gauge 4. Chuck key storage 10. Drill/impact action button (See Fig. F1, F2) 5.

  • Page 6: Technical Data

    ORIGINAL INSTRUCTIONS TECHNICAL DATA 230-240V~50Hz Voltage 500W Power input 0-3000/min No load speed 0-48000bpm Impact rate 13 mm Chuck capacity Drilling capacity 10 mm Steel 13 mm Masonry 25 mm Wood Protection class 1.4kg Machine weight NOISE INFORMATION A weighted sound pressure 100dB(A) A weighted sound power 89dB(A)
  • Page 7 ORIGINAL INSTRUCTIONS WARNING: To be accurate, an estimation of exposure level in the actual conditions of use should also take account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle but not actually doing the job. This may significantly reduce the exposure level over the total working period.

  • Page 8: Operating Instructions

    ORIGINAL INSTRUCTIONS OPERATING INSTRUCTIONS Insert the depth gauge through hole in handle. Slide the depth gauge to required NOTE: Before using the tool, read the depth and tighten fully. instruction book carefully. 3. INSERTING A DRILL INTO CHUCK INTENDED USE (See Fig.

  • Page 9: Working Hints For Your Drill

    Fig.C Fig.F1 ORIGINAL INSTRUCTIONS Continuous use Depress on/off switch (5) then lock-on button(3)(See Fig. D), release on/off switch first and lock-on button second. Your switch is now locked on for continuous use. To switch off your tool just depress and release the on/off switch.

  • Page 10: Maintenance

    ORIGINAL INSTRUCTIONS MAINTENANCE PLUG REPLACEMENT Remove the plug from the socket before Your Power Tool is supplied with a fitted carrying out any adjustment, servicing plug, however if you need to fit a new plug or maintenance. follow the instruction below. Your power tool requires no additional lubrication or maintenance.

  • Page 11: Environmental Protection

    In the event of a problem with the product within the guarantee period please return it to your nearest Argos store. If the item is shown to have an inherent defect present at the time of sale, the store will provide you with a replacement.
