Summary of Contents for Argos CDI114G4
- Page 2 14.4V LI-ION CORDLESS HAMMER DRILL INSTRUCTION MANUAL CDI114G4 ORIGINAL INSTRUCTIONS...
-
Page 3: General Power Tool Safety Warnings
ORIGINAL INSTRUCTIONS GENERAL POWER TOOL 3. PERSONAL SAFETY a) Stay alert, watch what you are doing and SAFETY WARNINGS use common sense when operating a power WARNING! Read all safety warnings tool. Do not use a power tool while you are and all instructions. -
Page 4: Drill Safety Warnings
ORIGINAL INSTRUCTIONS with the power tool or these instructions 2. Use auxiliary handle(s), if supplied with the to operate the power tool. Power tools are tool. Loss of control can cause personal injury. dangerous in the hands of untrained users. 3. -
Page 5: Safety Warnings For Battery Pack
ORIGINAL INSTRUCTIONS pack under extremes of temperature or after by ARGOS. Do not use any charger other heavy use, then wash off immediately from than that specifically provided for use with your skin and hands using clean water. For the equipment. A charger that is suitable for one... - Page 6 Please recycle where 18. Charge only battery pack of the same facilities exist. Check with your local model provided by ARGOS and of models authorities or retailer for recycling recommended by ARGOS. advice. SYMBOLS...
-
Page 7: Component List
ORIGINAL INSTRUCTIONS COMPONENT LIST Keyless chuck Torque adjustment ring Forward/Reverse rotation control On/off switch Soft grip handle Battery pack Battery pack release button Sight light Not all the accessories illustrated or described are included in standard delivery. HELPLINE NO 03448012949... -
Page 8: Technical Data
ORIGINAL INSTRUCTIONS TECHNICAL DATA Type CDI114G4 (CDI -designation of machinery, representative of Cordless impact Drill ) Voltage 14.4V No load speed 0-700/min Impact rate 0-10500bpm Number of clutch positions 21+1+1+1 Max torque 15N.m Chuck capacity 10mm Charging time 3-5hr Charger Input 100-240V~50/60Hz,0.2A... - Page 9 ORIGINAL INSTRUCTIONS examples and other variations on how the tool is used: How the tool is used and the materials being cut or drilled. The tool being in good condition and well maintained. The use the correct accessory for the tool and ensuring it is sharp and in good condition. The tightness of the grip on the handles and if any anti vibration accessories are used.
-
Page 10: Intended Use
ORIGINAL INSTRUCTIONS OPERATING INSTRUCTIONS charge. WARNING: When battery charge runs NOTE: Before using the tool, read the out after continuous use or exposure instruction book carefully. to direct sunlight or heat, allow time for the battery to cool down before re-charging to INTENDED USE achieve the full charge. - Page 11 ORIGINAL INSTRUCTIONS pressure. Speed is controlled by the amount of switch trigger depression. WARNING: Do not operate for long periods at low speed because excess heat will be produced internally. Fig.E2 4. CHUCK ADJUSTMENT (See Fig. F) To open the chuck jaws rotate the front section of the chuck.
-
Page 12: Problem Solution
ORIGINAL INSTRUCTIONS recycling and/or disposal options. Discharge your battery pack by operating your drill, then remove the battery pack from the drill housing and cover the battery pack connections with heavy-duty adhesive tape to prevent short circuit and energy discharge. Do not attempt to open or remove any of the components. -
Page 13: Maintenance
ORIGINAL INSTRUCTIONS 3. REASONS FOR DIFFERENT BATTERY PACK WORKING TIMES Charging time problems, as above, and having not used a battery pack for a prolonged time will reduce the battery pack working time. This can be corrected after several charge and discharge operations by charging &... - Page 14 In the event of a problem with the product within the guarantee period please return it to your nearest Argos store. If the item is shown to have an inherent defect present at the time of sale, the store will provide you with a replacement.
