- Page 1 Solutions BA346–K Series Deskside Expansion Pedestal User’s Guide Order Number EK–BA346–UG. A01 This guide describes the procedures for installing, configuring, and maintaining the BA346–K series deskside expansion pedestal. Digital Equipment Corporation Maynard Massachusetts...
- Page 2 Consult the dealer or an experienced radio/TV technician for help © Digital Equipment Corporation 1995 All Rights Reserved. Printed in the United States of America. HSJ, StorageWorks, and the DIGITAL logo are trademarks of Digital Equipment Corporation. This document was prepared using Microsoft Word for Windows 6.0®...
-
Page 3: Table Of Contents
1.2 Options ............................1–2 1.3 Major Components........................1–3 1.4 Power............................1–4 1.5 Device Cooling .......................... 1–6 1.6 StorageWorks Building Blocks (SBBs)..................1–7 1.7 Product Specifications........................ 1–8 Chapter 2 Installing and Operating the Pedestal 2.1 Installing a Pedestal ........................2–1 2.2 Selecting the Installation Area ....................2–2 2.3 Unpacking a Pedestal ......................... - Page 4 Figures Figure 1–1 BA346–KB Deskside Expansion Pedestal..............1–1 Figure 1–2 BA346 – Rear View ...................... 1–4 Figure 1–3 DC Power Distribution ....................1–4 Figure 1–4 Pedestal Air Flow......................1–6 Figure 1–5 Typical 3.5–Inch SBB ....................1–7 Figure 2–1 Pedestal Dimensions ..................... 2–1 Figure 2–2 Pedestal Packing ......................
- Page 5 Connecting the internal SCSI bus Cabling • Setting the configuration address • Setting device addresses Related Documents The following is a list of other StorageWorks user documents applicable to pedestals. Document Title Order Number StorageWorks Solutions BA346–KB Deskside Expansion EK–346AA–IG Pedestal 5.25-Inch Device Installation Guide StorageWorks Solutions BA346–KB Deskside Expansion...
- Page 6 Documentation Conventions The documentation conventions in this guide are as follows: boldface type Boldface type indicates the first instance of terms being defined in the text, the glossary, or both. italic type Italic type indicates emphasis and complete publication titles. In the glossary, italic type indicates cross-references.
-
Page 7: Chapter 1 Introducing The Deskside Expansion Pedestal
This chapter is an introduction to the BA346–KB series deskside expansion pedestal, commonly referred to as the “pedestal.” This description includes the options, components, power and cooling requirements, StorageWorks building blocks (SBBs), and specifications. 1.1 Product Description Figure 1–1 BA346–KB Deskside Expansion The standard BA346–KB deskside expansion... -
Page 8: Options
5.25-inch storage device in the top of the pedestal. This option increases the total number of devices on a 16-bit bus to nine. See StorageWorks Solutions BA346–KB Deskside Expansion Pedestal 5.25-Inch Device Installation Guide for detailed information about installing and configuring this option. -
Page 9: Major Components
1.3 Major Components The user is responsible for providing the following components, which are available through your Digital account representative: • AC power cord with NEMA 15 connector (see Table 1–3) • Storage Devices—5.25-inch devices and 3.5-inch SBBs • SCSI cables (BN21K or BN21L) Table 1–1 lists the major pedestal components supplied with the basic unit and each option. -
Page 10: Power
1.4 Power The ac power supply (switch-selectable 115 V ac or 230 V ac input), is located in the rear of the pedestal as shown in Figure 1–2. Figure 1–3 shows the internal dc power distribution, Table 1–2 lists the power supply specifications, and Table 1–3 lists the country specific ac power cords. -
Page 11: Table 1-3 Recommended Country-Specific Ac Power Cords
Table 1–3 Recommended Country-Specific AC Power Cords Length Digital Country Voltage Amps Connector Type Plug Type Order No. Australia 250 V ac 10 A IEC 320 C13, C14 AS3112 – 1981 BN19H–2E Central Europe 250 V ac 10 A IEC 320 C13, C14 CEE 7/7 (Schuko) BN19C–2E Denmark... -
Page 12: Device Cooling
1.5 Device Cooling Proper device operation requires cooling. The two fans in the pedestal and in the power supply. • The fan mounted on the rear of the pedestal cools the storage devices. • The power supply internal fan cools the 5.25-inch devices and the power supply. As shown in Figure 1–4, both fans draw air through the front of the pedestal, through the storage devices, and exhaust it out the rear. -
Page 13: Storageworks Building Blocks (Sbbs)
1.6 StorageWorks Building Blocks (SBBs) The pedestal supports only 3.5-inch form-factor storage devices in a modular carrier, an SBB (see Figure 1–5). The StorageWorks Solutions Configuration Guide lists the pedestal compatible 3.5–inch storage devices. Figure 1–5 Typical 3.5–Inch SBB CXO-4379A-MC The following primary factors determine the compatible storage devices: •... -
Page 14: Product Specifications
1.7 Product Specifications Table 1–4 lists the basic product specifications. Table 1–4 BA346–KB Pedestal Specifications Physical Specifications Item Dimension Height 533 mm 21 in Width 203 mm 8 in Depth 483 mm 19 in Rear clearance (air exhaust) 305 mm 12 in Front clearance (door opening) 305 mm... -
Page 15: Installing A Pedestal
Installing and Operating a Pedestal This chapter describes the procedures for installing and operating a BA346–KB series deskside expansion pedestal. Subjects addressed include selecting the installation area, unpacking the pedestal, installing storage devices, connecting cables, and checking pedestal operation 2.1 Installing a Pedestal You can usually install the pedestal within 2 meters (6.6 feet) of the SCSI controller and next to an ac receptacle. -
Page 16: Selecting The Installation Area
2.2 Selecting the Installation Area The location of the pedestal depends upon the availability of ac power and the distance to the SCSI controller. SCSI bus length is critical to selecting the installation area. Therefore, before selecting the installation area, read Section 3.3. CAUTION Blocking or restricting the input or output air flow can cause overheating. -
Page 17: Figure 2-2 Pedestal Packing
Figure 2–2 Pedestal Packing FOAM BLOCK DOOR WITH USER SHIPPING DOCUMENTATION SLEEVE BA346-KB SHIPPING CARTON CXO-4633A-MC Installing and Operating a Pedestal 2–3... -
Page 18: Packing A Pedestal
2.4 Packing a Pedestal WARNING To prevent personal injury always use two people to pack, unpack, or move the pedestal in the shipping container. Complete the following procedures to pack a pedestal for shipping: CAUTION To prevent damage to the pedestal, you must use the approved packing materials and pack the pedestal as described in this procedure 1. -
Page 19: Preparing The Pedestal For Operation
2.5 Preparing the Pedestal for Operation Preparing the pedestal for operation involves the following procedures: • Mounting the base (BA35X–VB option) • Installing options (BA35X–AA, BA35X–AB) • Configuring the pedestal (optional) • Installing the storage devices • Connecting the power and SCSI bus cables •... -
Page 20: Installing Options
2.7 Installing Options Complete the procedures described in the individual option installation guides. 2.8 Configuring the Pedestal The pedestal is factory-configured as a single SCSI bus with the device addresses shown in Figure 2–4. You can use the procedures in Chapter 3 to change the configuration. Figure 2–4 Standard BA346–KB Configuration SCSI ADDRESS 0 INPUT... -
Page 21: Installing Sbbs
2.9 Installing SBBs After installing the options and configuring the pedestal, you can install the SBBs. Be sure that you have set the storage device addresses before installing the devices in the pedestal. The combinations of the SBB guides, shelf slots, and backplane connectors preclude installing an SBB incorrectly;... -
Page 22: Connecting The Scsi Bus Cables
2.10 Connecting the SCSI Bus Cables Once you have installed all the storage devices, you can connect the SCSI bus cable. CAUTION Connecting the SCSI bus cable with power applied to either the controller or the pedestal can generate erroneous signals and cause the SCSI bus to “hang.” Always turn off the power on both the host and the pedestal when connecting or disconnecting the SCSI cables. -
Page 23: Connecting The Ac Power Cord
Figure 2–9 Rear Panel Connectors INPUT OUTPUT CONNECTORS CONNECTORS BUS "A" BUS "AB" BUS "A" BUS "B" BUS "A" BUS "AB" BUS "B" CXO-4557A-MC 2.11 Connecting the AC Power Cord Complete the following steps to connect the ac power cord: 1. -
Page 24: Operating The Pedestal
2.12 Operating the Pedestal Use the pedestal power switch, a “push-to-make, push-to-break” type, to turn on the pedestal. The pedestal power switch is shown in Figure 2–11. When the ac power is on the green pedestal power LED is on (see Figure 2–11). When the SCSI bus is active the LEDs on the 5.25-inch devices and the SBBs indicate the status of the storage devices. -
Page 25: Mounting The Door
2.13 Mounting the Door Once the pedestal is operating you can install the door to provide security for the storage devices. (A locked door precludes removing storage devices.) Figure 2–13 shows how to mount the door by inserting the hinge pins on the door into the holes in the bezel. Figure 2–13 Mounting the Door HINGE CXO-4554A-MC... -
Page 26: Replacing A Storage Sbb
2.14 Replacing a Storage SBB There are three methods for replacing a storage SBB with an identical SBB: • Hot swap —This method requires that the SCSI controller support removing and installing SBBs while the bus is active, Check the controller documentation to determine if hot swap is supported. -
Page 27: The Standard Configuration
Configuring the Pedestal This chapter describes the standard BA346–KB pedestal configuration and how to change it. 3.1 The Standard Configuration You can install the dual bus and the 5.25-inch device option at any time. Installing either option requires changing the pedestal configuration. Digital recommends that you install the options during the initial installation. -
Page 28: Scsi Bus Cables And Accessories
3.2 SCSI Bus Cables and Accessories After installing the options, there are two parts to configuring a pedestal—connecting the internal cables and setting the configuration address. Most cabling configurations and all SCSI address configurations are compatible. However, be sure to check Table 3–5 (page 3–7) for a description of each configuration. -
Page 29: Scsi Buses
3.3 SCSI Buses The reliability of data transfers on a SCSI bus is a function of the following: • The bus transmission rate • The bus type (8-bit or 16-bit) • The maximum SCSI bus length (a function of the bus type, the transmission rate, and the use of SCSI bus converters) •... -
Page 30: Internal Scsi Buses
3.4 Internal SCSI Buses Figure 3–3 shows the three internal SCSI bus configurations. Digital recommends that the internal SCSI bus length be kept as short as possible. The total internal SCSI bus cable length is distance from the controller terminator to the pedestal terminator. -
Page 31: Removing The Side Panel
3.5 Removing the Side Panel Whenever you configure the pedestal, you must complete the following procedures: 1. Turn off the power to both the controller and the pedestal. 2. Disconnect the pedestal power cord. 3. Disconnect the external SCSI bus cables. 4. -
Page 32: Setting The Configuration Address
3.6 Setting the Configuration Address There are both configuration addresses and device addresses. Jumpers W1-W3 determine the eight configuration addresses that can be used for both 8-bit (addresses 0-6) and 16-bit (addresses 0-6 and 8-14) devices. Note SCSI device address 7 is the SCSI controller address. Use jumpers W1-W3 to set the address configurations. -
Page 33: Table 3-5 Standard Configuration Addresses And Slot Addresses
Table 3–5 Standard Configuration Addresses and Slot Addresses Configuration 1 c c SCSI Addresses c c c (Dual Bus only) Slot 0 Address 0 c SCSI Addresses Configuration 2 c c c Standard Slot 0 Configuration Address 0 Configuration 3 c c SCSI Addresses c c c Slot 0... -
Page 34: Device Addresses
3.7 Device Addresses You can assign the device SCSI bus addresses in the following ways: • Jumpers on the device • Device address switches on 8-bit removable media SBBs as described in the SBB User’s Guide • Using the slot connector address as determined by the jumpers (see Section 3.6) The basic rules for setting devices are: •... -
Page 35: Glossary
Modular carriers are available in both 3.5-inch and 5.25-inch form-factors. pedestal An enclosure, commonly referred to as a pedestal, that houses a StorageWorks shelf in a vertical position. This pedestal contains the power supply and a cooling fan. The user supplies the storage SBBs and an ac power cord. - Page 36 StorageWorks building block. A device housed in a standard StorageWorks SBB carrier. An SBB has a standard physical and electrical interface that is compatible with those of StorageWorks shelves and enclosures. SCSI Small computer system interface. An ANSI interface defining the physical and electrical parameters of a parallel I/O bus used to connect hosts to a maximum of seven devices.
- Page 37 word This term indicates the size of a data construct. The bus width determines the number of bytes in a word, for example: Bus Width Word Length 8-bit 1 byte 16-bit 2 bytes 32-bit 4 bytes Glossary–3...
-
Page 39: Index
Index SCSI cable, 2–8 —5— —I— —C— 5.25-inch device option, 1– Input voltage, 2–9 Cables Installing a pedestal, 2–1 BN21K cable, 2–8 —A— —L— BN21L, 2–8 connecting, 2–5 Addresses LEDs connecting SCSI bus, 2– 16-bit devices, 3–8 5.25-inch device status, 8-bit devices, 3–8 2–10 power, 2–5... - Page 40 3–1 3.5-inch, 1–7 specifications, 1–4 internal, 3–4 installing, 2–5 connecting, 2–9 internal bus "A", 3–4 StorageWorks building cord, 2–9 internal bus "AB", 3–4 blocks. See SBBs input voltage, 2–9 internal bus "B", 3–4 Swapping SBBs, 2–12 switch, 2–10 internal cables, 3–2...
