Box Contents
Storm24 (pn:70050)
•
Straight connect Ethernet lead (pn:79102)
•
IEC power cord (country dependent plug)
•
User manual (pn: 50479)
•
CD (pn:79106)
•
Physical Features
24 DMX ( RJ-45) ports (output only)
•
Gigabit Ethernet Connection
•
LCD display provide status information on system
•
and data flow
Software Features
Refresh rate is configurable for each DMX port
•
(1Hz to 44Hz per second)
Break time is configurable for each DMX port
•
(88us to 1ms)
Mark After Break configurable for each DMX port
•
All
configurations
•
browser.
Graphical User Interface for creating and editing
•
ports is flow-chart oriented and documents data
flow as you configure it.
STORM 24
are
made
through
( P N 7 0 0 5 0 )
Number of channels configurable for each DMX port
•
(1 to 512)
Supports following DMX over Ethernet protocols:
•
◦ ESP
◦ Art-Net
◦ StreamingACN
◦ KiNet
DMX Generator and Stream snapshot (web)
•
Additional Features (Upgrade)
Stream Auditor
data throughput statistics, DMX values in real time, and
other information for troubleshooting, available through
web page. Ability to peek into each stream and check
current values through the web browser.
Safety
Do not expose the unit to rain or moisture, doing
•
this will void the warranty
Do not remove the cover, there are no serviceable
•
parts inside
web
This unit is intended for indoor use only
•
Since the Storm 24 is designed to run 24/7, the fan
•
will always remain on, however it can be disabled if
needed.
Quick Start Manual
50479 (STORM24)
for more information visit:
enttec.com/storm24
: A status monitoring screen that includes
1
Advertisement
Table of Contents
Related Manuals for Enttec STORM 24
Summary of Contents for Enttec STORM 24
-
Page 1: Box Contents
• This unit is intended for indoor use only • browser. Since the Storm 24 is designed to run 24/7, the fan • Graphical User Interface for creating and editing • will always remain on, however it can be disabled if ports is flow-chart oriented and documents data needed. -
Page 2: Basic Setup
Basic Setup Ethernet Streams These are the DMX over Ethernet universes. (Art-Net, ESP, KiNET, ACN) ENTTEC Storm24 is a standard Art-Net node. Because of this, you can use the device with applications, consoles, Routing Diagram desks, or controllers that are compatible with Art-Net to The routing diagram is the visual representation of distribute Art-Net data via Ethernet network. -
Page 3: Main Menu
It will end up deleting all your network. user created profiles, as well as any saved settings. Please use this only when needed, or as directed by ENTTEC Pressing any of the panel buttons/keys will activate the support team. - Page 4 Quick Start Manual 50479 (STORM24) for more information visit: enttec.com/storm24 Once confirmed, Storm24 will stop the output engine and restart the system. While rebooting the LCD screen will change between a couple of screens, and the LCD Main Menu will only be visible, once the system is fully ready.
- Page 5 All modifications can be done using the DMX Grid Page. ESP Stream : ENTTEC Show protocol DMX over Ethernet stream (ESP). IP address is the destination address used when the stream is sending data only. Clock: Allows you to synchronize ALL DMX output only when the connected Input Stream is received.
-
Page 6: Firmware Update
NMU (Node Management Utility) is a free Windows and OSX application that is used to manage compatible ENTTEC DMX over Ethernet nodes. NMU will not directly allow you to configure the Storm24itself, but it can help you find your unit's IP address and then open a browser window to make the required changes. -
Page 7: Specifications
Due to continuous improvements and innovations of all ODE and related products can be ordered from our website ENTTEC products, specifications and features are subject or through your ENTTEC dealer using the following part to change without notice. numbers. Item...
