- Page 1 KMP7020 / KMP7021 Digital RCD (ELCB) Tester Users Manual...
- Page 3 KMP7020 Digital RCD (ELCB) Tester with Fast Trip KMP7021 Digital RCD (ELCB) Tester with Auto Ramp Users Manual June 2011, Rev.1 ©2011 Amprobe Test Tools. All rights reserved. Printed in China...
- Page 4 Please check the “Where to Buy” section on www.amprobe.eu for a list of distributors near you. European Correspondence Address* Amprobe® Test Tools Europe Robin-Amprobe® Test Tools UK Beha-Amprobe GmbH 52 Hurricane Way In den Engematten 14 Norwich, Norfolk, NR6 6JB...
- Page 5 KMP7020 / KMP7021 Red (Live) Green ( Earth ) Blue ( Neutral ) LCD Display Connecting Terminals for Test Lead PHASE Button Rotary Mode Switch I n Button Indicators for Wiring Connection TEST Button Test Lead...
-
Page 6: Table Of Contents
KMP7020 / KMP7021 CONTENTS SYMBOLS .......................2 UNPACKING AND INSPECTION ................2 SAFETY INFORMATION ..................2 FEATURES .......................4 OPERATION ......................5 SPECIFICATION ......................8 MAINTENANCE AND REPAIR ................9... -
Page 7: Symbols
SYMBOLS � Double Insulation or Reinforced insulation Caution! Risk of electric shock � Caution! Risk of danger (see Safety Information) � Complies with European Directives Do not dispose of this product as unsorted municipal waste. Contact a qualified recycler for disposal UNPACKING AND INSPECTION Your shipping carton should include: KMP7020 or KMP7021 Digital RCD (ELCB) Tester... - Page 8 Safety sign“�”has three meaning in this manual, user has to pay the attention to this sign“�”for operation. DANGER! : identifies conditions and actions that most likely pose � hazard(s) or death. WARNING! : identifies conditions and actions that will pose hazard(s) or �...
-
Page 9: Features
FEATURES The Robin-Amprobe RCD Tester allows the testing of trip times of standard RCDs and selective RCDs using various residual currents: • This tester is suitable for use under single phase 230 V / 50 Hz. -
Page 10: Operation
• Phase Selection: Can select positive (0°) or negative (180°) to initiate a test. • Over-range display “OL” indication. “OL mS” signal will be displayed on LCD if the testing goes over the time limitation for the test. • Fast Trip Fixed: Current 250mA (MAX: 40mS) (KMP7020 only). •... - Page 11 1. Test Lead Connection installation: L to L(Line); N to N(Neutral); E to E(Earthing). 2. Check for proper connection Plug the power cable on a (230V/50Hz voltage adapter). L-E & L-N LEDs ON and RED LED off, the connection is correct. Otherwise, the connection is incorrect, do not proceed the test..
- Page 12 Tripping Test X1 (500mA): Maximum Tripping Time 300ms Fast Tripping Test X5 (10,20,30mA only):Maximum Tripping Time 40ms Fast Tripping Test 250 mA: Maximum Measuring Time 40ms (KMP7020 only) AUTO RAMP TEST Auto Ramp Test (KMP7021 only). 20%~110% Default nominal residual currents(I n).
-
Page 13: Specification
SPECIFICATION At Temperature: 23±5°C; Humidity: 45%~75% RH; Altitude below ≤2000 meter KMP7020 Accuracy Trip Current Trip Time Function Voltage(AC) Setting Trip Current Trip (MAX) Time 10 /20 /30 Tolerance: X 1/2 /100 /300 2000mS -10%~0% /500mA 230V 10 /20 /30 (Tolerance: ±2% 1000mS... -
Page 14: Maintenance And Repair
Measurement Application (Functions) • ×1/2 non-tripping test for RCD sensitivity. • ×1 tripping test of an RCD. • ×5 fast tripping test of I n×5 time. • 250mA tripping test of an RCD (maximum tripping time 40ms, for KMP7020 only) •...
