Jung JKB 1 Operating Manual

REVOLVING TRANSPORT TROLLEY JKB
JKB 1
Type
Load capacity
kg/ lbs
Number of castors
each
Castor dimension  x L
mm/ inch
Height
mm/ inch
Supporting surface
mm/ inch

of load pad
Trolley dimension L x W
mm/ inch
Weight
kg/ lbs
RECOMMENDED USE
Transport trolleys:
are specially designed for transport of heavy loads on solid level floors in

factories. Do not exceed the maximum load capacity recommended by
this operating manual.
are extremely manoeuvrable. Never use trolleys on uneven or declining

floors - this can lead to danger due to the potential of run-away loads.
Must not be used:

- for transport on public streets and places
for transport of people or animals

in extreme environments (e.g. under hazardous, explosive, flammable or

corrosive conditions)
Use only as directed. The manufacturer or supplier is not liable
for any damage resulting from improper use of the trolleys.
Accidents resulting from improper use are the responsibility of
the user.
The user should read these operating and service instructions carefully
before using the trolleys. In particular, attention should be paid to the
Safety Instructions on page 3
OPERATING MANUAL
Please read before starting work
JKB 3
JKB 1
1 000 / 2 200
3
75 x 60 / 3 x 2.4"
110 / 4.3"
215 / 8.5"
390 x 340 / 15.4 x 13.4"
10 / 22
CONTENTS
Technical Data, application................................................... 1
General information, operating instructions.................................... 2
Safety instructions, Spare parts.....................................................
Declaration of conformity..............................................................
JKB 3
3 000 / 6 600
8
85 x 40 / 3.3 x 1.6"
110 / 4.3"
250 / 9.8"
575 x 460 / 22.6 x 18.1"
32 / 71
JKB 4
JKB 4
4 000 / 8 800
12
85 x 40 / 3.3 x 1.6"
110 / 4.3"
250 / 9.8"
690 x 640 / 27.2 x 25.2"
51 / 112
