C
M
EILING
OUNTING
1)
Position the unit on the mounting surface so that the lens points toward the area you want to view.
2)
Mark the position of the mounting holes and cable hole (see Figure 1).
3)
Screw the provided #6x1-inch screws halfway into the mounting surface.
4)
Cut a hole in the mounting surface to accommodate the camera cables.
5)
Attach the camera's video out BNC connector (see Figure 2) to the receiving device's video in BNC connector.
6)
Attach the camera's power cable (see Figure 2) to your power source.
7)
Feed the cables through the hole.
8)
Place the mounting holes over the screws and turn the unit clockwise.
9)
Tighten the mounting screws until snug.
Figure 1. Mounting holes
1036339B / January 2003
DS-150/850/450/950/1200/1500 4-inch Mini-Dome Cameras
Mounting holes (2)
Cable hole
Camera base
Figure 2. Parts of the camera
Technical Support: 800-469-1676
Camera base
Camera
Power cable
Video out BNC
1
