Randell 20000 SERIES Operator's Manual

OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
1055 Mendell Davis Drive, Jackson, MS 39272
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WARNING Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
MODEL LENGTH
20048-513 48"
20048-32-513 53"
20072-513 72"
20072-32-513 82"
20078-513 78"
20105-513 105"
20105-32-513 120"
DEPTH HEIGHT DRAWERS
32.5" 26" (2) 27"
32.5" 26" (2) 32"
32.5" 26" (4) 27"
32.5" 26" (2) 32"
32.5" 26" (4) 27"
32.5" 26" (6) 27"
32.5" 26" (6) 32"
Information contained in this document is known to be current and accurate at the time of printing/creation. Unified Brands recommends
referencing our product line websites, unifiedbrands.net, for the most updated product information and specifications. © 2018 Unified Brands.
All Rights Reserved. Unified Brands is a wholly-owned subsidiary of Dover Corporation.
This manual provides information for:
20000 SERIES SELF-CONTAINED
LOW PROFILE EQUIPMENT TABLES
RETAIN THIS MANUAL FOR FUTURE REFERENCE
NOTICE: Due to a continuous program of product improvement, Unified Brands
reserves the right to make changes in design and specifications without prior notice.
NOTICE: Please read the entire manual carefully before installation. If certain
recommended procedures are not followed, warranty claims will be denied.
MODEL NUMBER _________________________
SERIAL NUMBER _________________________
INSTALLATION DATE ______________________
The serial number is located in the mechanical
housing. An example is shown here.
12x20x4
HP
PAN CAPACITY
4 1/4
4 1/4
8 1/3
8 1/3
8 1/3
12 1/2
12 1/2
PART NUMBER PP MNL1712, REV. A (09/18)
VOLT AMPS NEMA
115 6 5-15P
115 6 5-15P
115 7.4 5-15P
115 7.4 5-15P
115 7.4 5-15P
115 12 5-15P
115 12 5-15P
SHIP WT
(LBS)
400
400
530
530
530
675
950
