MD711-SU Installation Guide
• 1 MD711-SU system unit
• SATA mounting screws
• M.2/Mini PCIe mounting screws
• 1 CD disk includes:
- Drivers / Manual

Front Panel

Rear Panel
Line-out
Mic-in
DC-in
Note:
The USB 2.0, LAN and COM ports provide galvanic isolation up to
circuitry of the electonic devices connected with each other.
DFI reserves the right to change the specifications at any time prior to the product's release. For the latest revision and details of the
installation process, please refer to the user's manual.

Package Contents

DVI-D
USB 3.0
DP
USB 2.0
www.dfi.com
1
LAN 2
COM 2
LAN 1
COM 1
3kVac/4kVdc
to prevent damaging
HDD LED
(green)
Power Button
with LED (blue)
