Electrical Parts List - Sangean WR-11 Service Manual

WR-11
000YE0S1C
PART NO.
1012892 CH IC XC62FP2002PRN
1013663 CH IC UTC4580E SOP8
1013760 IC L7808CV TO-220
1014010 CH IC XC61CN2402MRN
1014821 CH IC HEF4066BT
1015240 CH IC LD1117AL33 AA3-AR
1017010 IC TDA7266SA
1018990 CH IC Si4835-B30-GU SSOP-24
1021051 TR 2SB834L-Y-TF3-T TO-220F
1022560 CH TR 2SC1623-L6 SOT-23
1041241T DIODE FR204-T
1046011 CH DIODE MM4148
1053270 LED GRN 5φ 50AZC2D-009
1053300 LED GRN 3Ø 30AZC1D-005
1058073 LED GRN 4.5Ø 444GM1D-001/G97
1111900 BAR ANT & COIL 1900 AM
1150172 TOROID COIL 600uH 17.5Ø
116224K2U17 WOUND-V 220μHK 6Øx8
1315224 R-VR 20KB RV110TF-40E1
131AF2F CH R-VR 200KB RD15L1134002
1320396 S.F-VR 100K TB067A-0D
1618420 PCB A WR-11B 1.6T/1
1618620 PCB P WR-11B 1.6T/1
1621350 SPK 3" 8Ω 10W
1631520 SILD SW.1P2C
1631990 ROT/SW2612F-0403-15F5B
1640040 JACK EP 3.5φ W/SW GRN
1640060 JACK EP 3.5φ W/SW BLK
1640161R JACK EP 3.5Ø N/SW ST RED
1646050 AC SOCKET HJC-037AP
1647110 JACK DC HTJ-020-04AZ
1650150 X'TAL 32.768KHZ±10Ppm 2×6
1701H2502V023 HOUSING 2.5×2P-V
1701H2503V013 HOUSING 2.5×3P-V
1701H2505V013 HOUSING 2.5×5P-V
1701H2508V023 HOUSING 2.5×8P-V
17031015502U CNT/W-A 100(2.5+5P)
17031615204U CNT/W-A 160(2.5+2P)
17032215203U CNT/W-A 220(2.5+2P)
17032215204U CNT/W-A 220(2.5+2P)
17038005302U CNT/W-A 80(2.5+3P)
17062215207U CNT/W-S 220(2.5+2P)

ELECTRICAL PARTS LIST

DESCRIPTION Q'TY
1 IC4,
1 IC401,
1 IC402,
1 IC5,
1 IC3,
1 IC2,
1 IC400,
1 IC1,
1 Q400,
3 Q1,Q401,Q402,
3 D400,
D300A,D301A,
3 D1,D2,D401,
2 LED503,LED504,
1 LED505,
3 LED500,LED501,LED502,
1 L2,
1 L300A,
1 L400,
1 VR200,
1 VR2,
1 SVR1,
1
1
1
1 SW2,
1 SW200,
1 JK402,
1 JK401,
1 JK403,
1 JK300A,
1 JK400,
1 X1,
4 CN400,CN401,CN402,CN7,
2 CN5_2,CN6,
1 CN4,
1 CN5,
1 JW500,
1 POWER WIRE,
1 SP WIRE,
1 AM EXT,
1 JW200,
1 JW1,
15
Date：2014/05/22
REMARK
