To Do Wireless LAN (Wi-Fi®) Connections via Manual Settings
This section explains how to connect to wireless LAN (Wi‑Fi®) using a Mac OS computer
and iPad/iPhone/iPod touch as examples.
1
Tapping [Manual connection] on the Setup Wizard shows the screen below.
Confirm the following information for this product.
• SSID(Primary) (SPWN_N35_xxxxxx)
• Password (AES) (13 alphanumeric characters)
<How to confirm using the display (touch panel)>
Home screen - [Information] - [Wi-Fi Information]
* This section explains what to
do for a primary SSID, without
using the " Wi-Fi Settings
Moving" Function.
Home screen
Wi-Fi Information
[For Mac OS]
2
6
接続済み
状
Turn the PC on and enable the wireless
If [
(Connected)] is displayed in [
function.
況
(Status)], tap [Next] on the product to
* Refer to the user manual, etc., for your PC for how
return to
.
to connect.
3
On the Apple menu, click the [
システム環境
設定
(System Configuration)] - [
ネットワーク
(Network)] icon and select [Wi-Fi] from the
service list.
4
From the [
ネットワーク名
(
Network Name)]
pulldown menu, select the SSID(Primary) of
this product
, "
SPWN_N35_xxxxxx
",
that was
1
displayed in
.
5
Enter the password for this product in [
パ
ス ワ ー ド
接 続
(Password)], and then click [
(Connect)].
* This example screen is from a macOS High Sierra
v.10.13.
If a connection could not be made, check the
text that you input (such as capital/small letter
case) and that the wireless function for your PC
1
is enabled, and then retry from step
.
[For iPad/iPhone/iPod touch]
2
Start your iPad/iPhone/iPod touch and tap [Settings].
* Refer to the user manual, etc., for your device for how to connect.
3
Tap [Wi-Fi].
4
Turn on [Wi-Fi], and tap the SSID(Primary) of this product, "SPWN_N35_xxxxxx", that was
1
displayed in
.
5
Enter the password for this product
in [Password], and then tap either
[Connect] or [Join].
* This screen is an example using iOS 11.4.
6
If the following icon is displayed in the status bar of your iPad/iPhone/iPod touch, tap [Next] on
the product to return to
.
If a connection could not be made, check the text that you input (such as capital/small letter
1
case) and that the wireless function for your device is enabled, and then retry from step
.
Using a QR Code to Connect to Wireless LAN (Wi-Fi®)
You can use the smartphone application "NEC WiMAX 2+ Tool" to connect to
wireless LAN (Wi‑Fi®).
*The "NEC WiMAX 2+ Tool" smartphone application has a Japanese user interface.
1
4
Open "NEC
Enter the
password, and
WiMAX 2+ Tool".
then tap [
保存
2
In the main screen
(Save)].
of the "NEC WiMAX
接
2+ Tool", tap [
続設定ウィザード
(Setup Wizard)].
3
Tap the [
①パス
ワードの設定
• Take note of the password (administrator password) as
(Password
it will be required in order to configure the product. If
Settings)] button.
you have forgotten the administrator password, it will
not be possible to access the screen of Quick Setting
Web and it will be necessary to initialize the product
and redo all configurations.
Password Memo
* Write it down in the location described in the
enclosed
つなぎかたガイド
"Setup Guide" (Japanese).
Configuring the Connection Destination
Connecting Wide Area Network (WAN)
Launch Quick Setting Web
1
Open the web browser on the wireless LAN (Wi-Fi®) device (such as a smartphone) connected to the
product in
.
2
Tap the Power button
to turn off the display.
Settings cannot be done on this product for Quick Setting Web while the display (touch panel)
is on. Additionally, operating this product's display (touch panel) while setting Quick Setting
Web may interrupt the settings on Quick Setting Web.
3
Open Quick Setting Web for the product.
実行
Type "http://192.168.179.1" into the address bar in the web browser and either tap [
(Execute)]
開く
or [
(Open)], or press the Enter key on the keyboard.
<< Example of Google Chrome's screen for mobile phones >>
<< Example of Microsoft Edge's screen for PCs >>
4
Tap or click [Advanced Settings Top] in the screen of Quick Setting Web.
[Advanced Settings
Top] button
5
Perform initial settings for administrator password.
パスワード
Type a password (any string of characters) in the [
(password)] (Re enter) field and
tap or click [Apply].
* Numbers 0 - 9, letters a - z and A - Z, hyphens (-) and underscores ( _ ) may be used in the password. A password
may be up to 64 single-byte characters.
This password will be required every time you open "Quick Setting Web" for the product.
Make sure that you do not lose this password.
* This screen is displayed when the administrator password is not set.
Administrator
Password Field
Administrator Password Memo
Tap or click
* Write it down in the location described in the enclosed
つなぎ
かたガイド
"Setup Guide" (Japanese).
6
名前
ユーザー名
Type "admin" for the [
(Name)] or [
(Username)] and the "administrator password"
5
set in
for the [
パスワード
(Password)], and then tap [
ログイン
(SIGN IN)] or click [OK].
admin
Administrator Password
Tap or click
5
7
Tap the
In the Camera View screen, read the QR Code for
[
②
Wi-Fi
設定
the Wi-Fi settings from the product's screen.
(Wi-Fi Settings)]
button.
Sample
• How to display the product: In the home
screen, display [Settings] - [Easy Wireless
Settings] - [Rakuraku QR] - [Primary SSID], and
6
In the Wi-Fi
then in the confirmation screen, tap [YES] to
settings screen,
display the QR Code.
tap [OK].
8
Next, tap [
設定適用
(Apply)] on the screen, and
then tap [OK] in the confirmation screen.
• In the "NEC WiMAX 2+ Tool" main menu, tap
情報更新
[
(Refresh)], and you can confirm
the product's information, and change
the wireless LAN (Wi-Fi®) bandwidth and
communication mode.
Configuring the Connection Destination
Connecting Wide Area Network (WAN)
(Continued)
Configuring the Connection Information
Connecting to Wide Area Network (WAN)
●
• Follow the procedures below to add profiles when information required for internet connection (user
name, password etc.) is specified by your WiMAX operator.
• If the WiMAX operator to whom you are subscribed specifies a preset profile, select the profile in [Settings] ‑
[Network Settings] ‑ [APN Settings] in the home screen. If there is no such information provided, you can use
the profile (Profile name "Internet") of this product to connect to the internet.
When using a smartphone/tablet
When using a PC
(Android device)/iPad/iPhone/iPod touch
1
ネットワーク設定
プ
1
ネットワーク設定
Tap [
(Network Settings)] - [
Click [
(Network Settings)] -
ロファイル設定
プロファイル設定
(Profile Settings)].
[
(Profile Settings)].
2
プロファイル
2
プロファイル
After selecting [no setup] in the [
After selecting [no setup] in the [
リ ス ト
(Profile List)], tap [
選 択
(select)], enter
リ ス ト
(Profile List)], click [
選 択
(select)], enter
the setup information such as the APN of the
the setup information such as the APN of the
WiMAX operator to whom you are subscribed,
WiMAX operator to whom you are subscribed,
設定
設定
and tap [
(Apply)].
and click [
(Apply)].
* The displayed content may be grayed out.
* The displayed content may be grayed out.
* If you have any questions, please check with the
* If you have any questions, please check with the
WiMAX operator to whom you are subscribed.
WiMAX operator to whom you are subscribed.
3
詳細設定
へ
3
ネットワーク設定
Tap [
TOP
(Advanced Settings
Click [
(Network Settings)] -
Top)].
[
接続設定
(Connection Settings)].
4
Tap [
ネットワーク設定
(Network Settings)] - [
接
4
In the Profile Selection, select the profile
2
設定
続設定
(Connection Settings)].
which you selected in step
, and click [
5
In the Profile Selection, select the profile which
(Apply)].
2
設定
Tr y o p e n i n g a w e b s i t e t o v e r i f y t h e
you selected in step
, and tap [
(Apply)].
Tr y o p e n i n g a w e b s i t e t o v e r i f y t h e
connection.
connection.
Connecting via Bluetooth® Function
Use this product as an access point to connect Bluetooth® equipped devices, such as a
smartphone or tablet, to the internet. It is efficient for saving energy if you are worried about
your battery endurance when away from home.
Up to 3 devices can be connected to the product via the Bluetooth® function. (For pairing, up to
3 devices can be registered.)
However, depending on the
Tablet
connection status of your
WAN
Bluetooth® equipped device, the
number of connected devices
The product
Smartphone
may not reach the limit.
Bluetooth®
* The wireless LAN (Wi-Fi®) function (on the previous page) and the Bluetooth® function cannot be used simultaneously.
• If Bluetooth® is disconnected after pairing, tap the Bluetooth device name for this product on the Bluetooth screen of the
Bluetooth® equipped device you are using to reconnect.
• When the number of paired devices reaches the limit, "You cannot configure because the number of connected devices has
got to the maximum. " is displayed on the product's display. In that case, delete pairing information displayed in "Bluetooth
Pairing Info" on "Bluetooth Settings" in the screen of Quick Setting Web.
• Confirm that your Bluetooth® equipped device supports Bluetooth 2.1 or later.
• Confirm that your device supports the profile (PANU), which can connect to the internet.
* For models that support PANU, see the manufacturer's website for each Bluetooth
®
equipped device.
About Communication Modes
The product has the following
Confirm that the connection status icon is
communication modes.
displayed on the status bar.
• "High Speed" mode (
) (default setting)
• The "Onetime HS+A" mode is used to temporarily
• "High Speed Plus Area" mode (
)
switch to the "High Speed Plus Area" mode when you
• "Onetime HS+A" mode (
(green))
move to an area where communications using "High
Speed" mode are not possible.
In the home screen, tap [Quick Menu] ‑
[Communication Mode] or [Onetime HS+A].
* A separate designated additional charge may be incurred
if you set "High Speed Plus Area" mode or "Onetime
Select a communication mode, and then
HS+A" mode.
tap [YES] in the settings confirmation
screen.
About the Collective Settings
You can change to the settings recommended for
Menu
Overview of settings
how you want to use the product with a single
P r i o r i t i z e
Sets the product to maximum
touch from the product's display (touch panel).
High Speed
communication speed.
Do settings in the home screen's [Quick Menu] ‑
Standard
Sets the product to a good
[Collective Settings].
Setting
balance of communication
speed and continuous
operating time.
Prioritize
Sets the product to save energy
Saving
to extend the continuous
Battery
operating time by controlling
the communication speed,
signal transmission output, and
display settings.
Not
You can turn off the Collective
Collective
Settings function and set Energy-
Select a menu and tap [YES].
Settings
Saving Mode and adjust the
(Indivisual
brightness separately.
Setting)
(Saves the product's settings as
they are before being turned off)
* When using Collective Settings, specific settings
cannot be changed. Furthermore, the communication
speed and the transmission output of the wireless LAN
(Wi-Fi®) may change and reconnections may happen.
* To turn off the Collective Settings function, select [Not Collective Settings (Indivisual Setting)] and tap [YES] in the confirmation
screen.
(Saves the product's settings as they are before being turned off, so you should do the individual settings according to
how you want to use the product.)
Displayed Information
<Numerics input screen>
<Home screen and status icons>
<Settings menu screen>
①
②
③④⑤ ⑥
⑦
⑧
⑨
Status icons
⑩
Message
(Example) Input screen for the upper limit
Name
Indicator
State
① Reception level
Lit
Indicates the signal strength of Wide Area Network (WAN) in 4 levels
Lit
Indicates that the product is out of the service area
② Connection status
Lit
Indicates that the product is connected to the internet in High Speed mode
Lit
Indicates that the product is connected to the internet in High Speed Plus Area mode(*)
Lit (green)
Indicates that the product is connected to the internet in Onetime HS+A mode(*)
Lit
Indicates that the product is connected to the cradle (sold separately) in Wi-Fi Access Point Mode
③ Firmware update notification
Lit (blue)
Indicates that new firmware has been released and an update is required
④ Status of wired connection
Lit
Indicates that LAN is connected via USB
Lit
Indicates that the product is connected to the cradle (sold separately) and wired LAN
⑤ Status of Bluetooth® function
Lit
Indicates that Bluetooth® is on (the number on the lower right indicates the number of connected devices)
Off
Indicates that Bluetooth® is off
⑥ Wireless LAN (Wi-Fi®)
Indicates that the product is connected to the 2.4 GHz bandwidth (the number on the lower right indicates
Lit
bandwidth
the number of connected devices)
Indicates that the product is connected to the 5 GHz bandwidth (outdoors) (the number on the lower right
Lit
indicates the number of connected devices)
Blinking
Indicates that the product is confirming the channel that is in use
Indicates that the product is connected to the 5 GHz bandwidth (indoors) (the number on the lower right
Lit
indicates the number of connected devices)
⑦ Schedule
Lit
Indicates that the Schedule function is set
Lit (orange)
Indicates that the Schedule function is set and there is less than 10 minutes to power off
⑧ Energy-Saving mode
Lit (green)
Indicates that the product is running in Eco mode
Lit (green)
Indicates that the product is saving energy when the remaining battery level is low in Normal mode
Lit
Indicates that the product is running in Normal mode
Lit
Indicates that the product is running in High Performance mode
⑨ Battery status
Lit
Indicates the remaining battery level on a scale of 6 levels
*
1
Lit
Indicates that the battery is being charged
*
1
⑩ Displaying data usage
Indicates the current data usage (value of data usage accumulated/value of set upper limits)
The length of the bar indicates the proportion used
* A separate designated additional charge may be incurred when using High Speed Plus Area mode or Onetime HS+A mode.
*1: Green when "Long Life Charge" is on.
Initialization Method
When the product is not operating properly, or to bring back the default settings, perform
initialization by following the steps below. (This will delete all user settings and the screen
display will change to Japanese.)
1
Open the home screen on the product's display (touch panel).
2
From the home screen tap [Settings] - [Maintenance] - [Initialize].
3
Once the message "Restoring to the initial settings. Do you want to initialize this device?" is displayed
on the product's display (touch panel), tap [YES].
4
Initialization will be completed once the product has been reactivated.
Updating the Firmware
Follow the steps listed below to update the firmware.
1
Open the home screen on the product's display (touch panel).
2
Once the message "There is new firmware available. Do you want to
update?" is displayed on the product's display (touch panel), tap [YES].
3
"Now updating the firmware... Please do not remove the battery pack."
is displayed while the update is processing.
4
When the update is complete, the product automatically reactivates
and the home screen appears on the display.
Firmware cannot be updated when the product is connected to the cradle (sold separately) and used in Wi-Fi Access Point
Mode. Update the firmware when the product is removed from the cradle (sold separately) and "Access Point Mode" is set to
"Disable".
Troubleshooting
If you experience difficulty setting up an internet connection even when the instructions in the "Setup Guide" and the "
取扱説明書 詳細版
(Full Instruction Manual)" (Japanese) are followed, please check the following items.
Unable to connect to the
• Make sure that you are located in a service area.
internet
• The incoming signal strength may be low. Retry the connection in a location with a higher
incoming signal strength.
• If the "HS" or "HS+A" icon does not appear in the display, launch Quick Setting Web to check
that an internet connection has been properly set up.
Communication is easily
• The incoming signal strength may be low. Check the radio reception level and move to a
disrupted
location for a higher incoming signal strength.
• Check the remaining battery level. If the remaining battery level is low, recharge the battery
pack before reconnecting the product.
• Check to see if the product is properly connected to a PC, or the like, on a wireless LAN (Wi‑Fi®),
Bluetooth®, or by a USB cable.
• If the product is connected to a PC, or the like, on a wireless LAN (Wi‑Fi®) or Bluetooth®
function, reboot the product.
• If there is radio interference from other networks, such as multiple access points having been
set up in the vicinity, radio reception may be improved by changing "Channels" for the product.
• Confirm that this product has the latest firmware.
(How to confirm: Home screen ‑ [Settings] ‑ [Maintenance] ‑ [Firmware Update])
When "There is new firmware available. Do you want to update?" is displayed on the display
of this product, it indicates that a new firmware exists. In that case, refer to the "Updating the
Firmware" of this manual to update the version.
Co m m u n i c a t i o n s e e m s
• The connection point might be congested. Allow for some time before retrying.
slow
The charge in the battery
• If the Energy‑Saving Mode is set to "High Performance" mode, switch it to "Eco" mode.
seems to decrease quickly.
• Turn off "WiMAX High Power" in Network Settings.
Cannot connect to wireless
• In the home screen, set [Settings] ‑ [LAN Settings] ‑ [Wi‑Fi Management Frame]
to [OFF], and then you may be able to connect.
LAN (Wi‑Fi®)
■
Aterm is a registered trademark of NEC Corporation.
■
らくらく無線スタート
and
らくらく
QR
スタート
are registered trademarks of NEC Platforms, Ltd.
■
Windows is a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
iPhone and iPod touch are trademarks of Apple Inc. registered in the United States and/or other countries. App Store is a service mark of Apple Inc.
■
The iPhone trademark is used under license from Aiphone Co., Ltd.
■
■
United States and/or other countries.
Google, Android, Google Chrome, and Google Play are trademarks or registered trademarks of Google LLC.
Bluetooth and the Bluetooth logo are trademarks registered to Bluetooth SIG, Inc., and are being used under license.
DENSO WAVE INCORPORATED.
■
Other company names, brand names, service names and so on are trademarks or registered trademarks of their respective owners. TM and the ® mark may be omitted in this manual.
© NEC Platforms, Ltd. 2018 This manual may not be duplicated or altered, or duplicate copies of the manual distributed, without prior written permission from NEC Platforms, Ltd.
<Quick Menu screen>
<Collective Settings screen>
Numerics input
• [Firmware Update] is displayed when there is a new
firmware update.
• [Onetime HS+A] is not displayed when the
values of data usage
Communication Mode is High Speed Plus Area mode.
<Settings message display>
Explanation
This is displayed while doing settings for the product.
Displayed when
communicating
When sending When receiving
<Lock screen>
<Display while idling>
This is displayed when the Power button
is pressed.
Product Specifications
■ Main Unit
Physical dimensions (W × H × D)
Approx. 111 (W) × 62 (H) × 13.3 (D) mm
Weight
Approx. 128 g (Battery pack attached)
USB connector (USB 2.0 (type C)) × 1*
3
Interface
Compliant with Bluetooth 4.0 Wireless Technology
Display (touch panel)
2.4 inches (320 × 240 dots) color LCD
AC adapter
Power supply
AC 100 V to 240 V ± 10%, 50/60 Hz
Battery pack
Lithium-ion, 3.8 V, 3,200 mAh
Waiting state: Approx. 50 hours
Continuous standby time*
1
Idle state (Remote start available): Approx. 700 hours
Collective Settings (Standard Setting)/Normal mode
Approx. 690 minutes
Continuous communication time *
*
Collective Settings (Prioritize High Speed)/
1
2
Approx. 490 minutes
(High Speed mode: During Wi-Fi® connection)
High Performance mode
Collective Settings (Prioritize Saving Battery)/Eco mode
Approx. 840 minutes
Collective Settings (Standard Setting)/Normal mode
Approx. 630 minutes
Continuous communication time *
*
1
2
Collective Settings (Prioritize High Speed)/
(High Speed Plus Area mode: During Wi-Fi®
Approx. 480 minutes
High Performance mode
connection)
Collective Settings (Prioritize Saving Battery)/Eco mode
Approx. 800 minutes
Continuous communication time *
1
Eco mode
Approx. 1,080 minutes
(High Speed mode: During Bluetooth® connection)
Continuous communication time *
1
(High Speed Plus Area mode: During Bluetooth®
Eco mode
Approx. 1,010 minutes
connection)
Operating temperature range: 5°C to 35°C
Operating environment
Operating humidity range:
35% to 85% (with no condensation)
Approx. 160 minutes (when using the typeC Common AC Adapter 01 U (0601PQV) (sold
Charging time
separately))
*1: The continuous standby time and continuous communication time may vary depending on the communication network
being used.
*2: The continuous communication time when connected to a single wireless LAN (Wi-Fi®) device.
*3: Use of USB2.0 or later is recommended as a sufficient transfer rate cannot be achieved with USB1.1. It should be noted that
operation is not guaranteed with all computers.
■ WAN
Communication methods
WiMAX 2+, LTE
■ LAN
Communication methods
Wi-Fi (compliant with IEEE802.11a/b/g/n/ac), compliant with Bluetooth 4.0 Wireless Technology
Supported frequencies
Wi-Fi®: 2.4GHz / 5GHz, Bluetooth®: 2.4GHz
WEP (128 bit)
WPA2-PSK (AES)
Wi-Fi security methods
WPA / WPA2-PSK (AES)
WPA / WPA2-PSK (TKIP/AES)
Maximum number of simultane-
Wi-Fi®: 10 devices/USB: 1 device/Bluetooth®: 3 devices
ous connections*
* Wireless LAN (Wi-Fi®) and Bluetooth® cannot be used simultaneously.
■ USB2.0 TypeC-A cable (sample)
Length
Approx. 1.0 m
Weight
Approx. 27 g
USB 2.0 type A,
Interface
USB 2.0 type C
This product can be used on OSs, such as Windows®, Macintosh,
Windows® 10 supporting:
and Linux, that comply with the TCP/IP protocol stack (use limited
• Microsoft Edge
to Japanese versions of the OS).
• Internet Explorer 11.0
Windows® 8.1 supporting:
However, the following OSs are supported during USB connection.
• Internet Explorer 11.0
Windows® 10, Windows® 8.1, Windows® 7 (SP1 and later) Japanese
version, 32 bit (x86) version and/or 64 bit (x64) version, and macOS
Windows® 7 (SP1 and later) supporting:
• Internet Explorer 8.0/9.0/10.0/11.0
High Sierra v10.13 (Intel), Sierra v10.12 (Intel), OS X v10.11 (Intel),
macOS High Sierra v10.13/Sierra v10.12/OS X v10.11/v10.10/
v10.10 (Intel), v10.9 (Intel), v10.8 (Intel), Mac OS X, v10.7 (Intel),
v10.6 (Intel), v10.5 (Intel) Japanese versions.
v10.9/v10.8/v10.7/Mac OS X v10.6/v10.5 supporting:
• Safari
The following web browsers are available when performing
Android (8.1/8.0/7.1/7.0/6.0/5.1/5.0/4.4/4.3/4.2/4.1/4.0) supporting:
settings in Quick Setting Web.
• Google Chrome
Also, the supported products include the following OS pre-
iOS (11.4/11.3/11.2/11.1/11.0/10.3/10.2/10.1/10.0/9.3/9.2/9.1/9.0/
installed products, or products which are guaranteed by
8.4/8.3/8.2/8.1/8.0) supporting:
manufacturers to use with the following OSs. (Self-made
• Safari
computers are not supported.) (As of September, 2018)
■
Mac, Macintosh, Mac OS, macOS, OS X, iPad,
■
Internet Explorer is a trademark or registered trademark of Microsoft Corporation in the
■
"QR Code" is a registered trademark of
November, 2018, 1st Edition
Sold by: KDDI CORPORATION, OKINAWA CELLULAR TELEPHONE COMPANY
Manufactured by: NEC Platforms, Ltd.
Advertisement
