Superior Electric SLO-SYN SS2000MD4M-O Installation Instructions Manual

Microstep drive/oscillator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
INSTRUCTIONS
for
®
SLO-SYN
MODEL SS2000MD4M-O
MICROSTEP
DRIVE/OSCILLATOR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLO-SYN SS2000MD4M-O and is the answer not in the manual?

Questions and answers

Related Manuals for Superior Electric SLO-SYN SS2000MD4M-O

Summary of Contents for Superior Electric SLO-SYN SS2000MD4M-O

  • Page 1 INSTALLATION INSTRUCTIONS ® SLO-SYN MODEL SS2000MD4M-O MICROSTEP DRIVE/OSCILLATOR...
  • Page 2 ENGINEERING CHANGES Superior Electric reserves the right to make engineering refinements on all its products. Such refinements may affect information given in instructions, Therefore, USE ONLY THE INSTRUCTIONS THAT ARE PACKED WITH THE PRODUCT. RECORD OF REVISION Revision Date Description...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION Page THINGS TO KNOW BEFORE USING THIS EQUIPMENT ................3 WARRANTY INFORMATION............3 SECTION 1: INTRODUCTION ............3 1.1 Using This Manual ............3 1.2 Product Features .............. 4 SECTION 2: EXPRESS START UP PROCEDURE ......5 SECTION 3: INSTALLATION GUIDELINES ........
  • Page 4 FIGURE Page 3.1 Mounting Diagram..............6 3,2 Terminal Locations ..............7 3.3 Motor Wiring Configurations............ 9 3.4 Typical Power Supply for a Single Unit Application..... 10 4.1 Switch and Potentiometer Locations ........14 4.2 Suggested Methods for Control Interface........16 4.3 Timing Considerations ............

  • Page 5: Things To Know Before Using This Equipment

    THINGS TO KNOW BEFORE USING THIS EQUIPMENT • Only qualified personnel should install or perform servicing procedures on this equipment. • Before performing any work on the unit, allow at least five minutes for the capacitors to discharge fully. • Voltage is present on unprotected pins when the Drive/Oscillator is o p- erational.

  • Page 6: Product Features

    Appendix A provides procedures for troubleshooting electrical interference problems. 1.2 - PRODUCT FEATURES The SLO-SYN SS2000MD4M-O Drive/Oscillator combines a bipolar, two-phase PWM drive which uses hybrid power devices and a con- trol/oscillator in one compact package. Micro-stepping at 1/32 step resolu- tion (6400 pulses/revolution) is used to ensure smooth low speed opera- tion.

  • Page 7: Section 2: Express Start Up Procedure

    SECTION 2: EXPRESS START UP PROCEDURE The following instructions define the minimum steps necessary to make your Drive/Oscillator operational. CAUTION: Always disconnect the power to the MD4M-O before connecting or dis- connecting the motor leads. FAILURE TO DO THIS WILL RESULT IN A SHOCK HAZARD AND MAY DAMAGE THE DRIVE.

  • Page 8: Section 3: Installation Guidelines

    SECTION 3: INSTALLATION GUIDELINES 3.1 - MOUNTING The MD4M-O is mounted by fastening its mounting brackets to a flat surface. Dimensions are shown in Figure 3.1. If the Drive/Oscillator assembly is mounted against a bulkhead, be sure to apply a thin coating of thermal com- pound (such as Dow Corning type 340 Silicone Heatsink Compound) be- tween the Drive/Oscillator and the mounting surface before fastening the unit in place.

  • Page 9: Terminal Locations And Assignments

    3.2 - TERMINAL LOCATIONS AND ASSIGNMENTS Figure 3.2 shows the terminal locations for the SLO-SYN SS2000MD4M-O Drive/Oscillator. Motor and Power I/O Connector Supply Connector (J1) (J2) Figure 3.2, Terminal Locations SS2000MD4M-O Page 7...

  • Page 10: Motor Connections

    Cabling from the Drive/Oscillator to the motor should be done with a shielded, twisted-pair cable. The wires for each motor phase should be twisted together about six times per foot (0.3 m). Superior Electric offers the following motor cable configurations. These ca- bles have unterminated leads on both ends. Length...

  • Page 11: Motor Wiring Configurations

    MOTOR MOTOR TERMINAL "M" NUMBERS MOTOR CONNECTOR PIN CONNECTOR PIN WHITE/ DRIVE PIN 1 DRIVE PIN 4 BLACK WHITE/ DRIVE PIN 2 DRIVE PIN 3 BLACK GREEN 4-LEAD MOTORS DRIVE PIN 1 DRIVE PIN 4 GREEN * N.C. WHITE BLACK N.C.* WHITE/ WHITE/...

  • Page 12: Power Input Connections

    3.2.2 - POWER INPUT CONNECTIONS The dc input power is connected to terminals 5 and 6 of the 6-pin terminal strip (J2). Terminal 5 [Vm(+)] is the power supply plus (+) connection and pin 6 [Vom (-)] is the power supply minus (-) connection. An unregulated supply similar to that shown in Figure 3.4 is preferable.

  • Page 13: Section 4: Specifications

    SECTION 4: SPECIFICATIONS 4.1 MECHANICAL SPECIFICATIONS Size (Inches)....1.56 H x 4.13 W x 3.25 D (mm) ...... 40 H x 105 W x 83 D Weight ......10.3 ounces (292 grams) 4.2 ELECTRICAL SPECIFICATIONS DC Input Range..... 24 Vdc min., 40 Vdc max. DC Current....
  • Page 14 MOTORS FOR USE WITH THE SS2000MD4M-O DRIVE/OSCILLATOR Current Power Supply Current Motor Winding Connection Setting Standstill Maximum (Amperes) (Amps. DC) (Amps. DC) M061 Series M061 Parallel M062 Series M062 Parallel M063 Series M063 Parallel M091 Series M091 Parallel M092 Series M092 Parallel KML060F08...

  • Page 15: Switches And Potentiometers

    4.5 SWITCHES AND POTENTIOMETERS 4.5.1 Current Settings The proper current setting for each motor is shown on the indivi dual torque vs. speed curves. Use this current level to obtain the torque shown. Switches 1 through 5 are used to select the current level. Select the desired operating current by setting the appropriate switch to position 1 (ON).

  • Page 16: Potentiometers

    4.5.5 Potentiometers On board potentiometers are provided for setting the following motion p a- rameters: Accel, Decel, Low Speed, and Run Speed. Run Speed can also be set via: a) external potentiometer, see Section 4.5.3. b) external voltage input 0-5V or 0-10V, see Section 4.5.4. This product is implemented using digital techniques.

  • Page 17: Signal Specifications

    4.6 SIGNAL SPECIFICATIONS 4.6.1 I/O Terminal Assignments All connections are made via the 7-pin terminal strip. J1 Pin Assignment LOW SPEED EXT SPEED 4.6.2 Signal Descriptions Low Speed Input (J1-1) SPEED When this input is activated (tied to GND) the Run Speed is set by the Low Speed potentiometer.

  • Page 18: Timing Considerations

    4.6.3 Level Requirements External Speed input (EXT SPEED) Voltage .......... 0 to 10 VDC Input Impedance......100K ohms I/O Signals Voltage Low........≤ 2.0 and ≥ 0.0 VDC High ........≥ 3.0 VDC Open Circuit Input Voltage ..5 VDC typ. Current Logic 0 sink current ....

  • Page 19: Timing Considerations

    All of the switch settings, potentiometer settings, and input signals can be changed "On-the-Fly" with the new settings, except DIR, effective immedi- ately. The following diagrams depict the timing relationships between the RUN in- put, motor speed, and motor current. SW6 (Auto Reduce Current Disable) OFF MOTOR SPEED Motor Speed with...

  • Page 20: Indicator Lights

    4.8 INDICATOR LIGHTS "FAULT" LED, Red Lights to indicate over current condition. This condition is caused by motor wiring errors or a ground fault. Recovery from an over current condition requires removing and then reap- plying the power. SECTION 5: TORQUE VERSUS SPEED CHAR- ACTERISTICS 5.1 MOTOR PERFORMANCE All stepper motors exhibit instability at their natural frequency and harmonics...

  • Page 21: Typical Torque Vs. Speed Curves

    5.2 TYPICAL TORQUE VERSUS SPEED CURVES NOTE: The test conditions used when obtaining the torque versus speed data are listed in the lower left-hand corner of each curve. SS2000MD4M-O Page 19...
  • Page 22 Page 20 SS2000MD4M-O...
  • Page 23 SS2000MD4M-O Page 21...
  • Page 24 Page 22 SS2000MD4M-O...
  • Page 25 SS2000MD4M-O Page 23...
  • Page 26 Page 24 SS2000MD4M-O...
  • Page 27 SS2000MD4M-O Page 25...
  • Page 28 Page 26 SS2000MD4M-O...

  • Page 29: Section 6: Troubleshooting

    SECTION 6: TROUBLESHOOTING WARNING: Motors connected to the MD4M-O can develop high torque and large amounts of mechanical energy. Keep clear of the motor shaft and all parts mechanically linked to the motor shaft. Turn off all power to the Drive/Oscillator before performing work on parts mechanically coupled to the motor.
  • Page 30 Improper motor wiring Grounded or shorted wiring to the motor or shorted motor Improper motor type or incorrect Current Select switch setting If a malfunction occurs that cannot be corrected by making the preceding checks, contact Superior Electric. Page 28 SS2000MD4M-O...

  • Page 31: Appendix A: Troubleshooting Electrical Interference Problems

    1. Check the quality of the ac line voltage using an oscilloscope and a line monitor, such as the Superior Electric VMS series. If line voltage problems exist, use appropriate line conditioning, such as line filters or isolation transformers.
  • Page 32 Notes: Page 30 SS2000MD4M-O...
  • Page 33 WARRANTY AND LIMITATION OF LIABILITY Superior Electric (the "Company"), Bristol, Connecticut, warrants to the first end user pur- chaser (the "purchaser") of equipment manufactured by the Company that such equip- ment, if new, unused and in original unopened cartons at the time of purchase, will be free...
  • Page 34 In addition, Superior Electric sales engineers are conveniently located to provide prompt attention to customers' needs. Call the nearest office listed for ordering and application information or for the address of the closest authorized distributor.
