Kintech Engineering EOL Zenith Quick User Manual page 5

EOL ZENITH DATA LOGGER |
2. Setup your data logger
HOW TO SETUP YOUR FIRST EOL ZENITH DATA LOGGER
All the settings for the EOL Zenith data logger are stored in a file called .sit. This configuration file is prepared by
using the EOL Manager. When you are done with the configuration you have to upload the configuration file to the
data logger.
Start the EOL Manager. From the dashboard in EOL Manager go to Options > License Information and type in your
software license.
Main dashboard
Go to File > New Logger. This opens up a window where you can con-
figure all the settings for your first data logger. You also have the
option to import an already prepared standard configuration file
(.sit). Please ask our tech support team for this and/or go to your on-
line user account and look under "important documents and files."
Site info tab
1. Type in the unique serial number of your data logger in the field
marked "Serial Number."
2. Select a "Site Number" that makes it easier for you to organize all
your future wind measurement sites.
3. Choose a name for your new site, language to display in the data
logger, company, city, country, notes, etc.
Inputs tab
Here you setup all the sensors you are going to connect to the data
logger as well as the data you want to collect from each sensor. For
now you can choose to use the standard slope and offset and then
later adjust these values to the real values given on your calibra-
tion certificates. Adjust the averaging time and gust integration as
needed.
Logger communication tab
1. If you are going to download data via GSM/GPRS select the "GSM/
GPRS".
2. Enable the GPRS in case you have a SIM card with GPRS activated.
3. Type in the Mobile Operator Settings, APN Name, User Name and
APN Password.
4. Select the passwords for accessing your data logger.
5. If you want to receive data directly from the data logger via email,
fill in the required fields. We do not recommend downloading
data via email. It is easier and more reliable to use your internet
connection to connect directly with your data logger (via GSM/
GPRS).
support@kintech-engineering.com
QUICK USER GUIDE
.sit
www.kintech-engineering.com
