Salt Dogg Direct Drive Hydraulic Replacement Tailgate Spreader Installation Instructions Manual

Hide thumbs

Advertisement

Table of Contents

Installation Instructions
Direct Drive Hydraulic
Replacement Tailgate Spreader
REPLACEMENT TAILGATE SPREADER WARRANTY
This warranty replaces all previous warranties and no employee
of this company is authorized to extend any additional warranties,
or agreements, or implications not explicitly covered herein.
Buyers Products Company warrants all parts of the product to
be free from defects in material and workmanship for a period
of (1) one year from the date of original installation. Parts must
be properly installed and used under normal conditions. Normal
wear is excluded.
Any part which has been altered, including modification,
misuse, accident, or lack of maintenance will not be considered
under this warranty. The sole responsibility of Buyers Products
Company under this warranty is limited to repairing or replacing
any part(s) which are returned, prepaid, 30 days after such
defect is discovered, and returned part(s) are found to be
defective by Buyers Products Company.
Authorization from Buyers Products Company must be
obtained before returning any part. The following information
must accompany defective parts returned to Buyers Products
Company: RMA#, spreader model, serial number, date installed,
and distributor from whom it was purchased. Buyers Products
Company shall not be liable for damage arising out of failure of
any unit to operate properly, or failure, or delay in work, or for
any consequential damages. No charges for transportation or
labor performed on any part will be allowed under this warranty.
Phone (440) 974-8888 • Fax (800) 841-8003
Table of Contents
Spreader Installation Instructions ............................ 1-2
Spinner Assembly Instructions ................................ 3-4
Spinner Assembly Drawing ........................................ 4
Hydraulic Installation ............................................... 4-5
Operating Instructions .............................................5-6
Parts lists ................................................................. 7-8
Note: These instructions are for typical
installation. Your truck application may
require additional fabrication.
During installation ensure that the truck is on level ground and
the spreader will be safely supported the entire process.
1
9049 Tyler Blvd. • Mentor, Ohio 44060
www.saltdogg.com
WARNING
—continued inside
