- Page 1 SY S E M Keyboard X K111DX Installation User User Manual Version 2.3 2851-00005...
-
Page 2: Operation
SY S E M Operation In addition to the normal keys, the Keyboard X also uses so-called 'Soft Keys'. The function of the 'Soft Keys' depends on what selections the operator has made. The 'Soft Key symbols' in the keyboard LCD display, changes according to the selections made by the operator. Selected Site Selected Camera/DVR LonBox in control... - Page 3 SY S E M Next/Previous Camera Previous Camera Next Camera (Disabled if a DVR camera is selected). Display Text TEXT Toggles on/off Status Text, Camera Text and Time/Date, on the selected monitor. Options: All text OFF. Only Camera text ON. Camera text and Time/Date ON.
-
Page 4: Ptz Operation
SY S E M PTZ operation PTZ Control CONTROL Enables/disables PTZ control for the selected camera Using the joystick, or pressing one of the zoom/focus/iris keys, will also enable PTZ control. Zoom Ö Ö Tele Wide Focus Ö Ö Near Auto Focus AUTO Ö... - Page 5 SY S E M Pan/Tilt When controlling a variable speed Pan/Tilt, pushing the joystick towards its extremes will increase speed Auto panning (Soft Key) Starts Auto Panning at predefined speed. Ö Starts Auto Panning at e.g. 25% of maximum Pan Speed. Actual speed depends on Pan/Tilt used.
- Page 6 SY S E M Auxiliary Function (Soft Key) Ö Activate/Deactivate AUX relay 1, on the selected PTZ camera Direct Auxiliary Functions (Soft Keys) Ö Activate/De-activate the AUX relay Backlight Compensation (Soft Key) Toggle BLC on/off, on the selected PTZ camera Define Preset (Soft Keys) Ö...
-
Page 7: Camera Sequence
SY S E M Camera Sequence Start Sequence SEQUENCE Ö Starts Sequence 1 on the selected monitor Hold Sequence HOLD Pauses the sequence on the selected monitor. Pressing HOLD again, resumes the sequence. Alarm Operation Clear Alarm ALARM Clears the alarm currently active on the selected alarm monitor. -
Page 8: Alarm Enable/Disable
SY S E M Alarm Enable/Disable From the keyboard, the operator can enable/disable specific alarm inputs. The NodeManager software can generate a list, with the required alarm inforation. Ö Select alarm enable/disable menu. Select Site Ö Select the site number where the alarm is connected. Select Alarm Type Ö... -
Page 9: Holiday Setup
SY S E M Holiday Setup Up to 30 Holidays can be programmed 1 year ahead. Alarms activated on a Holiday will be handled according to the Alarm Zone setup in the NodeManager software. Ö Select Holiday setup menu. Set Holiday 2006 Ö... -
Page 10: Dvr Operation
SY S E M DVR operation When selecting a camera input, that has a DVR connected, the camera symbol will automatically change to a DVR control symbol. Take DVR control CONTROL Enables/disables DVR control of the selected DVR. DVR Monitors (Soft Keys) Main monitor Spot monitor 1 Spot monitor 2... - Page 11 SY S E M Direct Split Screen Modes (Soft Key) SHIFT Ö Direct selection of 9-way split, cameras 1-9. Ö 4-way, camera 1-4 Ö 4-way, camera 5-8 Ö 4-way, camera 9-12 Ö 4-way, camera 13-16 Ö 9-way, camera 1-9 Ö 9-way, camera 10-18 Ö...
- Page 12 SY S E M Menu Access (Soft Key) Access menu system. Some menus uses numeric selections, others are navigated using the joystick. For details on navigating the DVR menus, please see the Instructions for the DVR. Numeric Menu Selections SHIFT Hold 'SHIFT' and press number.
-
Page 13: Special Functions
SY S E M Special functions Day/Night/Auto mode (Soft Key) Ö Day (colour) Night (b/w) Auto For cameras/domes with Day/Night camera. Auto/IR mode (Soft Key) Ö Toggles between Auto and IR (b/w) mode. (Orion Dome only) Camera connection Status Ö Ö... -
Page 14: Macro Operation
SY S E M Macro Operation Macros (Soft Keys) Ö Macro soft key menu Start/Stop/Pause Macro (Soft Keys) Ö Macro No. Start Pause Stop LonBox Operation LonBox Control (Soft Key) Ö Takes control of LonBox 1 SHIFT Release control of LonBox LonBox Relays (Soft Keys) Ö... -
Page 15: Keyboard Setup
SY S E M Keyboard setup A few setup options are made available for the user. Language (Soft Keys) Ö Toggles between the four languages available (if programmed) Keyboard beeper (Soft Keys) Ö Beep OFF Beep ON Animate Softkeys (Soft Keys) Ö... -
Page 16: Dome Setup
SY S E M Dome setup When navigating the menu system on connected Domes, the following general keys can be used. Some Dome types may require special key combinations for specific menu operations. Please see the I151SX-DOME Installation Manual, for details. Access menu system MENU Access menu system. -
Page 17: Operator Messages
SY S E M Operator Messages The Keyboard X displays various operator messages for guidance, when e.g. wrong/invalid selections are made. Type your user ID. Press Next Key in your user ID defined during installation, and press Next (right arrow key). Type your password. - Page 18 SY S E M Monitor 'X' controlled by kbd. 'X' The selected monitor is being controlled by keyboard 'X', which has higher user priority. Monitor 'X' controlled by Alarm The selected monitor is in alarm mode, and can only be selected by the alarm keyboard defined during installation.
