Tense WASHINGTON J5803D Operation Manual

2B
1B
1A
2A
3A 3C
3D
2C
3F
3E
3B
4A
4F
4E
4D
4C
4B
WATCH MAINTENANCE
TO OPEN THE WOODEN BACK
1
1
3
2
1. Tools required: Narrow Nose Pliers
2. Place the tip of the pliers to the two holes of the
wooden back.
3. Hold the pliers firmly, carefully turn it counter-
clockwise until the back loosens.
TO ADJUST THE WOODEN BAND
1. Tools required: 1.4mm Precision Screwdriver
2. Locate the screw on the side of the link, then
loosen the screw to take out the link.
3. Put the link back, then tighten the screw.
1.4mm
1
1
2
1
1 3
2
TYPES OF WOOD
Sandalwood-A tropical wood that is recognized
throughout the world for its beauty and density. Both
the wood and the oil produce a distinctive fragrance
that has been highly valued for centuries. The wood
or its oil is used extensively in religious ceremonies
for faiths worldwide, including Hinduism, Buddhism,
Islam, Zoroastrianism, and more. Oils distilled from
the heartwood are highly sought after for use in
perfumes, incense, and medicines.
Dark sandalwood-obtained from a leguminous tree
( Adenanthera pavonina ) It was probably the almug
of the Bible. It is used chiefly as the source of a dye.
Inlaidwood/Wildwood-Natural dual-tone color
Sandalwood.
Rosewood-Hard reddish or dark wood with a
strongly marked grain. It is durable and is used in
all kinds of cabinetwork.
Maplewood-Hardwood, high density, fine grained,
even texture, consistent golden yellow colour with
light pattern. Can be worked to high degree of detail.
3
