Summary of Contents for Everest ECB36D2
- Page 1 Owner’s Manual for models: Chef Bases ECB36D2, ECB48D2, ECB52D2, ECB52-60D2 ECB72D4, ECB82D4, ECB82-84D4, ECB82-86D4, ECB96D4 A Step Above the Standard Thank you for choosing EVEREST ISO-9001...
-
Page 2: Safety Notices
Safety Notices Safety Notices REFRIGERATION WARNING - When using your appliance, always follow basic precautions, including the following : Before starting the unit for the frist time, When installing the unit, be careful that the make sure the unit is free from all packaging. electrical cord is not under the unit or Packaging left on the unit during operation pressed against the wall. - Page 3 A dedicated circuit of to its own circuit. EVEREST is not responsible su cient amperage is required. for any damage caused by improper electrical connections resulting from electrical power failure, use of extension cords &...
- Page 4 Caution! Caution! REFRIGERATION To prevent electrical shock and damage to Do not use the the electrical cord, please hold electrical cord the plug head or plug if they when plugging are damaged and unplugging in any way. the unit. Avoid installing the unit where it could Do not put your hands under the unit when be exposed to water or moisture.
- Page 5 Maintenance Guide Maintenance Guide REFRIGERATION Door Gasket Cleaning Plastic Pan Cleaning To preserve the life span of the drawer Periodically remove the pans from the unit gasket, clean the gasket with mild soap and and clean them with mild soap water on a regular basis.
- Page 6 IMPORTANT: Failure to clean the condenser coil will result in a void of warranty. Follow these simple steps at least once a month to ensure the proper operation of your Everest product. 1. Always unplug the unit before performing maintenance.
- Page 7 Condenser Coil Maintenance Condenser Coil Maintenance REFRIGERATION A type Diagram ECB-L-001-D3 B type Diagram ECB-L-001-D4...
-
Page 8: Installation Guide
Installation Guide Installation Guide REFRIGERATION Install the unit on a hard and level surface The unit should be positioned at least 7” or the unit could produce undesired noises. away from the wall for proper ventiliation. For side mount units, a 7” space should also wall. -
Page 9: Troubleshooting
Trouble Shooting Trouble Shooting REFRIGERATION Please check the following before requesting service Symptom Possible Solutions Condensing unit a. Ensure the electrical cord has not been fails to start disconnected. b. Ensure the unit is turned on. a. Check the drawer gaskets for proper seal. Cabinet does not b. - Page 10 (4) Vertical Pan Dividers (2) Vertical Pan Dividers (4) Vertical Pan Dividers [Note] Additional pan dividers are not included in the unit. They are optional. ECB36D2 (2) “A” Drawers ECB48D2 (2) “B” Drawers Warning - Do not attempt to adjust pan dividers when loaded!
- Page 11 Pan Configurations Pan Configurations REFRIGERATION Drawer Type - C Drawer Type - D Standard Standard (1) Vertical Pan Divider (2) Vertical Pan Dividers (1) Vertical Pan Divider (2) Vertical Pan Dividers (1) Vertical Pan Divider (2) Vertical Pan Dividers (3) Vertical Pan Dividers (5) Vertical Pan Dividers (3) Vertical Pan Dividers (5) Vertical Pan Dividers...
-
Page 12: Specification
Specifications Specification REFRIGERATION Model ECB36D2 ECB48D2 ECB52D2 ECB52-60D2 # of Pans 1 x 6 1 x 2, 1/6 x 6 1 x 4, 1/6 x 6 1 x 6 # of Drawers Compressor (HP) 1/4+ 1/4+ 1/4+ Power (V-Hz-Ph) 115-60-1... -
Page 13: Temperature Setting
Temperature Setting Temperature Setting REFRIGERATION * LED Display Operation of compressor Current cabinet temperature * Control Buttons Power button Temperature setting button Defrost button * How to set desired temperature Press and hold “ D ” button until the LED displays “ set ” symbol and a number Step 1 consecutively. - Page 14 Pan Configurations REFRIGERATION REFRIGERATION Chaf Bases ECB36D2 [Standard: (1) 1 size pans w/ 1 pan dividers per drawer included] / 4" Depth ECB48D2 [Standard: (1) 1 size pans w/ 2 pan dividers per drawer included] / 4" Depth ECB52D2 / ECB52-60D2 / ECB82D4 / ECB82-84D4 / ECB82-86D4 / ECB96D4 [Standard: (3) 1 size pans w/ 2 pan dividers per drawer included] / 4"...
-
Page 15: Product Drawings
4 1/2" of the unit. equipment from accidentally sliding off the unit. 1" 32 1/8" Air chamber & Vent 36 3/8" 21 3/4" 29 1/2" 22" ECB36D2 48 3/8" 51 7/8" 60" 41 1/8" 41 1/8" 35" ECB48D2 ECB52D2 ECB52-60D2... - Page 16 Product Drawings (continued) Product Drawings (continued) REFRIGERATION 72 3/8" 28 1/8" 28 1/8" ECB72D4 86 1/4" 84" 82 3/8" 95 1/2" 41 1/8" 28 1/8" 41 1/8" 41 1/8" ECB82D4 ECB82-84D4 ECB82-86D4 ECB96D4 • •...
-
Page 17: Critical Information
Critical Information Critical Information REFRIGERATION The warranty card below must be submitted to Everest within thirty (30) days of purchase. WARRANTY REGISTRATION CARD Business Name : Telephone : ( Address : City : State : Zip : Place of Purchase :... -
Page 18: Warranty Certificate
Our obligation under this warranty is limited to a period of three (3) years from the date of original installation or thirty six (36) months after shipment date from EVEREST, which ever occurs rst. - Page 19 Memo Memo REFRIGERATION REFRIGERATION...
- Page 20 REFRIGERATION REFRIGERATION A S tep Above the S tanda rd 201 W. Artesia Blvd., Compton CA 90220 Tel : 310-323-6586, 800-444-6285 Fax : 310-323-7524, 310-761-1127 Visit our website at www.EVERESTref.com...
