- Page 1 Rapidox 1100ZR3-H-PFC Oxygen Analyser (Heller Version) Instruction Manual Revision 1.2 Cambridge Sensotec Limited Unit 29 Stephenson Road St Ives CAMBS PE27 3WJ Tel. +44 (0)1480 462142 Fax +44 (0)1480 466032 Mobile (07866) 624236 Sales@Cambridge-Sensotec.co.uk...
- Page 2 UK users only: If you have purchased any electronic or electrical product from Cambridge Sensotec since 2007 and would like to dispose of it correctly under the WEEE scheme, please contact us and we will be happy to either arrange the collection of the waste or have it returned to our offices for recycling.
-
Page 3: Table Of Contents
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Contents Introduction ......................1 Features ......................... 1 Heller Specific Features ..................2 Technical Specification ..................3 Precautions ......................4 Warning ......................... 4 Rapidox Operating Instructions ................4 PFC Connections ................... 5 The Rapidox Analyser - Menu System ............6 Getting Started .................... - Page 4 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Introduction ....................34 Auto-Log Feature ..................34 Setting up the Data Logger ................34 Running the Data Logger ................36 Auto Date Stamped Files ................36 Live Time Graphing Screen ................ 37 Main Graph Window ...................
-
Page 5: Introduction
4 seconds for a 90% response to a step change in gas compositions. The Rapidox 1100ZR3-H-PFC is a fully integral unit complete with a powerful diaphragm pump to provide variable gas sampling up to approximately 1.2 litres per minute. -
Page 6: Heller Specific Features
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Large back-lit LCD display (16 x 2 characters). RS232, 0-10V and 4-20mA current loop outputs (both fully programmable). Fully programmable alarm circuits. Full data-logging software accessed via RS232 connection to a PC (RS485 available on request). -
Page 7: Technical Specification
Sample Pump Long-life vacuum pump Flow Rate 0-1.2 L.min Max. gas temperature on input 60°C Requires 2 or 3 user-selectable gas compositions (air is default plus another Calibration two) Table 1: Rapidox 1100ZR3-H-PFC technical specification Version 1.2 Last printed 22/07/2015 18:00:00... -
Page 8: Precautions
This unit is NOT designed for use in life support situations. No responsibility can be held for injury or loss of life caused by inappropriate use of this equipment. 7. Rapidox Operating Instructions Figure 1: Rapidox 1100ZR3-H-PFC front panel. Numbers are referred to in the text. Version 1.2 Last printed 22/07/2015 18:00:00... -
Page 9: Pfc Connections
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 2: Rapidox 1100ZR3-H-PFC rear panel. Numbers are referred to in the text. 7.1 PFC Connections On the rear of the PFC coded machines are two terminals labelled “PFC Valve 4- 20mA” and “Supply Valve (In)”. -
Page 10: The Rapidox Analyser - Menu System
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual The Rapidox Analyser - Menu System All of the user-programmable functions are accessed via a menu system which is controlled using the front panel Keypad (2). To access the menu press the ENT button and to escape and return to the operating screen press ESC at any time. -
Page 11: Pump Control
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Oxygen Sensor Display Possibilities Reading > 9999.9% Display shows “O/Range” Reading >0.5ppm and < 9999.9% Display shows the normal oxygen reading in % or ppm Reading <0.5ppm Display shows <0.5ppm flashing Indicates that the pressure sensor is out of range and Reading is flashing automatic pressure correction is on. -
Page 12: Rapidox Calibration
Pressing ESC takes you out of the password protected area and you will have to re- enter the password to go back in again. If the password has been forgotten please contact Cambridge Sensotec who will advise you on how to recover it. - Page 13 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Scientific Meaning Equivalent Equivalent Format Percent 1.000E+06ppm 1.000 x 1,000,000 1,000,000ppm 100.00% 2.095E+05ppm 2.095 x 100,000 209,500ppm 20.95% 1.000E+05ppm 1.000 x 100,000 100,000ppm 10.00% 1.000E+04ppm 1.000 x 10,000 10,000ppm 1.000% 1.000E+03ppm 1.000 x 1,000 1,000ppm 0.100%...
-
Page 14: Programming The Multiplex
NB You must always perform a FULL calibration to achieve good accuracy. Programming the Multiplex The Rapidox 1100ZR3-H-PFC is fitted with three independent gas inlets on the rear panel allowing up to three separate gas samples to be analysed. The... -
Page 15: Cleaning The Sensor
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual flash to indicate this. See Table 4 for more details. Symbol Meaning +/- “Man” In automatic mode sampling channel 1 for selected time. In manual mode channel 1 on and 2 & 3 off. -
Page 16: Alarms
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 7.10 Alarms The Rapidox is fitted with two independent and fully programmable alarm relay outputs, which can be programmed to be either normally open N/O (closes on alarm) or normally closed N/C (opens on alarm). You have the option of assigning each alarm to the oxygen, or pressure (internal) as well as enabling the alarm relay circuits, enabling an audible buzzer and enabling a visual warning on the screen. -
Page 17: Analogue Outputs
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual confirm that the settings have been saved. The alarm circuit relays are accessed via the terminal block on the rear panel and are clearly labelled. Alarm 1 is assigned to the terminals labelled “Alarm High”... - Page 18 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual The following general formulae can be used to calculate the oxygen from the voltage or current outputs when set to the linear output mode: Output type Formula for calculating oxygen from analogue output signal...
- Page 19 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Output type Formula for calculating log ) from analogue output signal 0-10V ) = V / 10 * log ) + log 4-20mA ) = (mA – 4) / 16 * log...
- Page 20 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Output type Formula for calculating sensor mV from analogue output signal 0-10V / 10 * (O ) + O 2mVH 2mVL 2mVL 4-20mA = (mA – 4) / 16 * (O ) + O...
-
Page 21: Setting The Display Units
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Notes: The current outputs are active self-powered outputs - they are not loop powered i.e. they are current source outputs. The voltage (0 to10V) outputs produce non-zero voltages during start-up, fault and over/under range conditions - if 1V to 5V outputs are required, with these conditions indicated by corresponding voltages between 0V and 1V, the current outputs can be used, with a 250 Ohm load resistor. -
Page 22: Pressure Correction Mode
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual option and press ENT to store and return to the main menu. The default setting is Pressure. Note that on the Heller coded machines the second line display is switched off by default. -
Page 23: Rs232 / Rs485 Port
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 7.16 RS232 / RS485 Port It is possible to factory set the data communications port to either RS232 or RS485. Once configured at the factory it is not possible to change unless the unit is returned to Cambridge Sensotec Ltd. - Page 24 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual RS232 Figure 8: Rapidox RS232 pin configuration All other pins (1,4,6,7,8,9) = Don’t care Reading Data: Data is read using command “D”. Send the single character “D” to the Rapidox. The Rapidox replies with one of the following responses. All valid responses end with [CR] &...
-
Page 25: Rs485 Protocol
“D” command was not recognised. Try to send it again. 7.16.2 RS485 protocol Please contact Cambridge Sensotec for further information on this feature. 7.17 Printing If you have purchased the printer option then you have the option to print out various data from the analyser straight on to thermal paper. -
Page 26: Load Defaults
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Cambridge Sensotec Ltd Rapidox 1100ZR3-H-PFC Oxygen Analyser S/N: 210XXXX FW v XX.XX.XX.XX 7.18 Load Defaults If you make a mistake programming the Rapidox it is possible to restore the machine back to its factory settings by loading the unique default configuration that is supplied on your software memory stick. -
Page 27: Rapidox Software Instructions
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 8. Rapidox Software Instructions Please note that additional instructions for the PFC pages of the software are supplied in Appendix 1 at the end of this manual as this feature is a “bolt on”... -
Page 28: On-Screen Help
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 9: Rapidox configuration page. Note the actual values used may differ from those shown above. The yellow status box at the bottom will display confirmation that the Rapidox was found and the result of the last action, or any error messages if there is a problem with communication. -
Page 29: Reconfiguring The Analyser
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual written to the Rapidox, the new variables remain permanent until overwritten. To read the current configuration stored in your Rapidox select ‘Read Analyser Configuration’ from the ‘File’ menu, or click the ‘Read’ button on any of the ‘Config’... -
Page 30: Config 1 Screen
The field parameters are as follows: 8.5.1 Config 1 Screen Oxygen Range: Not available for the Rapidox 1100ZR3-H-PFC Oxygen Units & Format: See Section 7.12 for a full description. Use the drop down box to select PPM EXPONENTIAL, PPM MIXED, AUTO%/PPM, PRESSURE or N BALANCE. -
Page 31: Config 2 Screen
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual mode or if manual mode is selected chose between “off” and “on” for each of the three channels. Note that you can re-label the three sample channels by clicking on the label text. The new names will be recorded and displayed on the graph to assist you. -
Page 32: Alarm Config Screen
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual low ppm value (e.g. 10ppm) would be approximately 180mV. Analogue Output (0V/4mA & 10V/20mA): Use these two boxes to set the High and Low oxygen values for the analogue outputs (6) on the rear panel. -
Page 33: On-Screen Lcd
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual enabled if you wish to use the signals from the alarm circuit. Audible Alarm: This option enables or disables the audible buzzer fitted to the Rapidox internally. When an alarm condition occurs the buzzer will emit a continuous noise to alert the operator. -
Page 34: Remote Calibrating And Cleaning
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual The blue LED indicator will flash to show that the display is updating. Remote Calibrating and Cleaning With the on-screen LCD display active it is possible to remotely calibrate the analyser and clean the sensor. Click on the down arrow icon in the bottom right- hand corner of the LCD display to expand the window: Figure 14: Remote calibration and clean function. -
Page 35: Calibration Error Messages
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 16: Calibration Gas Confirmation Screen. If the current stored value is correct and matches your cal gas value then simply click “Yes” to proceed. If you are using a different value to the one you see on the screen then click “No”... -
Page 36: Software Utilities
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual This normally indicates one of two things: that you are using the wrong cal gas value compared with the actual gas flowing over the sensor OR the sensor is getting old and can no longer output the expected signal required for a healthy calibration. -
Page 37: Setting Analyser Date And Time
8.11 Log Diagnostics For Use this option to log diagnostic data that can be e-mailed to Cambridge Sensotec to help diagnose problems. Select the time you want to log the data for and then wait for the logging to complete. During the diagnostic logging period the yellow status box will display the location of the logged data file which will be sent to the main Rapidox program directory. -
Page 38: Data-Logging Software
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 9. Data-Logging Software Introduction The Rapidox software includes a full data logging facility. Data can be saved to a file automatically at regular intervals and the format is compatible with modern spreadsheet programmes such as MS-Excel. A live-time graphing facility is also included which has many powerful features. - Page 39 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 22: Data Logging page During logging, data from the analyser is shown in the central area of this page. The data is displayed in the following columns: time (in seconds), the raw signal...
-
Page 40: Running The Data Logger
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual described in detail (sections 40,41 & 44). To start data logging select the frequency of measurement by entering a time and selecting a unit from the drop down list. For example if you wish to log data once every minute type 1 in the box and select ‘Mins’... -
Page 41: Live Time Graphing Screen
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual will prevent the computer from crashing and will also ensure that the data is small enough to fit into an Excel spreadsheet As an example, the user wishes to run the data-logger for seven days recording every minute starting at lunchtime on 12th November 2005. -
Page 42: Main Graph Window
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 23: Live-time graphing screen. The colours and labels can be edited by the user by double clicking on them. Main Graph Window The graph is an XY plot, with time plotted on the X-axis, oxygen plotted on the primary Y-axis (Y1) and pressure plotted on the secondary Y-axis (Y2). -
Page 43: Graph Titles And Labels
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 24: Plot colour palette menu accessed by double-clicking on the axes titles. Graph Titles and Labels If you want to change the text of the graph axis labels, place the mouse pointer over the text and do a single left click to enter edit mode. -
Page 44: Zooming
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual the left of the cursor position. The cursor can be used to investigate actual data values at specific points of interest on the graph. 9.13 Zooming You can zoom in to any part of the oxygen plot by simply placing the mouse pointer on the new graph start position and then clicking and dragging a new box to re-size the graph. -
Page 45: Printing Graphs
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 9.18 Printing Graphs You can print the graph at any time by selecting ‘Print Plot’ from the File menu. This will bring up the printer dialogue box for your specific printer where you can chose various printing options. -
Page 46: Disaster Recovery
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual The data-logger saves data files in a standard comma separated ASCII text format which can be readily imported into spreadsheet programmes such as MS Excel, in order to produce plots and reports as desired. For specific information on how to import text files into your spreadsheet programme please refer to the help guide supplied with the programme. - Page 47 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Desired O2 level window in PPM "RAPIDOX|Main!HighO2SetPoint" "RAPIDOX|Main!LowO2SetPoint" Current O2 level in PPM "RAPIDOX|Main!lbl_PPM_O2" Set to -1 when not measuring, see Error state for reason, -4 to indicate sensor fault and -5 to indicate under range error.
-
Page 48: Troubleshooting
If so then the heater may be struggling to heat the sensor with such cooling gas present. Does the problem go away if room air is allowed into the analyser? Contact Cambridge Sensotec for advice. If the message continues for around ten minutes then the analyser will give up and indicate that the internal heater has failed and the sensor needs replacing. -
Page 49: Warranty
Refer to the “Troubleshooting” section of your instruction manual to identify and possibly correct the problem. b] If the fault cannot be resolved, please contact the Cambridge Sensotec service and repair centre at the address given on the cover of the manual. - Page 50 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual b] such defects shall be found to have arisen from the Seller's faulty design, workmanship or materials, and c] The defective goods shall be returned to the Seller's premises at the Purchaser's expense if so requested by the Seller.
-
Page 51: Appendix 1: Proportional Flow Control
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 11. Appendix 1: Proportional Flow Control This appendix to the main Rapidox instruction manual describes the additional software functions that allow proportional flow control (PFC) using a Rapidox analyser. This is used for controlling the oxygen gas inside an oven or similar structure by operating a proportional flow valve. -
Page 52: Connections
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Figure 25: Config 1 software tab showing additional panel displayed at the bottom. This feature only applies to PFC versions of Rapidox. 11.1 Connections On the rear of the H coded machines are two terminals labelled “PFC Valve 4- 20mA”... -
Page 53: Prop. Flow Control Tab
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual 11.3 Prop. Flow Control tab Figure 26: PFC configuration page The on-screen edit boxes below the button labelled ‘write’ contain PFC variables that can be reprogrammed into the Rapidox. The user can choose whether to use ppm or percent notation to edit the text boxes, where appropriate, by selecting the ‘UNITS’... - Page 54 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual window. And so on. Regulation Low Point: As described above this value sets the lower limit of the target O window. Note that the low point can be set to the same value as the high point to give maximum control around a set point, but this is likely to cause the gas valve to “chatter”.
- Page 55 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual less than 1). Differential Regulation Gain: This is the “D” term in PID control. The D term is a ‘damping’ factor that attempts to prevent the reading overshooting the set-point. It is a very sensitive parameter that if incorrectly adjusted can introduce wild oscillations in the oxygen reading.
-
Page 56: Sw Alarm Config Tab
The alarm condition is also data-logged as shown in Figure 22 under the column labelled “Status” as a “0” (off) or “1” (on). If you are working with a Rapidox 1100ZR3-H-PFC with three gas inlets then Version 1.2 Last printed 22/07/2015 18:00:00... -
Page 57: Data-Logging With Pfc
Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual repeat this process for the remaining channels 2 and 3. Hold Channel Alarms: This only applies to the multi-channel Rapidox 1100ZR3-H-PFC analyser that is fitted with a multiplexer. If set to NO each channel’s alarms will cancel during times that the other channels are being... - Page 58 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Also note that the “save to file” and “auto-date stamped files” options are both selected by default in this version to ensure that data is always collected, saved and stored. The PFC signal can also be viewed on the Rapidox graph facility. Simply click on “show plot”...
- Page 59 Cambridge Sensotec Rapidox 1100ZR3-H-PFC O Analyser Instruction Manual Version 1.2 Last printed 22/07/2015 18:00:00...
- Page 60 APPENDIX 2: MENU FLOWCHART FOR RAPIDOX 1100ZR3-H-PFC ESC - Back to Menu List. No changes 2.095E+05ppm O2 Back to Measurements : Changes Applied 0.0mbar 1-Calibrate Calib: O High 2.095E+05ppm 2.087E+05ppm 2.095E+05ppm ® ® ® ® ® (prompts 1) (prompts 2) (prompts 3) ..
- Page 61 Continued from page 1 4-Set Alarms Set: Alarm 1 Assign to: O Outputs: On ® ® ® ® (Prompts 1) (Prompts 2) (Prompts 2) (Prompts 6) (Options: Alarm 1, Alarm 2) (Options: O , Press) (Options: On, Off) Audible: On Visible: On Polarity: ®...
- Page 62 ESC - Back to Menu List. No changes Continued from page 2 9-Set Baud Rate Baud rate: 57600 Baud rate: 57600 ® ® (prompts 1) (prompts 5) Baud rate set (Options: 9600, 57600) Displays message for 1.5 seconds 10-Set Pump Flow Pump Flow: 90% Pump Flow: 100% ®...
