S I N A P S I S . r . l .
V i a d e l l e Q u e r c e 1 1 / 1 3
0 6 0 8 3 B a s t i a U m b r a ( P G ) I t a l y
T . + 3 9 0 7 5 8 0 1 1 6 0 4 F . + 3 9 0 7 5 8 0 1 4 6 0 2
w w w . s i n a p s i t e c h . i t
i n f o @ s i n a p s i t e c h . i t
|
SIN.EQRPT868XT
868 MHz W. M-Bus
sinapsitech
User Guide
Rev 1.6
repeater
℗
This manual refers to the 1.23 Firmware
version
Advertisement
Table of Contents
Related Manuals for Sinapsi SIN.RPT868XT
Summary of Contents for Sinapsi SIN.RPT868XT
- Page 1 S I N A P S I S . r . l . V i a d e l l e Q u e r c e 1 1 / 1 3 0 6 0 8 3 B a s t i a U m b r a ( P G ) I t a l y T .
-
Page 2: Table Of Contents
SIN.EQRPT868XT – User Guide Rev. 1.6 TABLE OF CONTENTS INTRODUCTION ............................... 3 Purpose of the document ........................3 Content of the package ......................... 3 SIN.EQRPT868XT TECHNICAL SPECIFICATIONS ..................4 ASPECT OF THE SIN.EQRPT868XT ......................... 5 Description of the SIN.EQRPT868XT ....................5 SIN.EQRPT868XT device ......................... -
Page 3: Introduction
Also, the search for the best point of installation is facilitated by the ability to power the device through its USB port, making possible to move it during the search for the best signal / distance compromise. 1.2 Content of the package The following are present in the SIN.EQRPT868XT package: SIN.RPT868XT Repeater • 2 x 5x25 plugs •... -
Page 4: Sin.eqrpt868Xt Technical Specifications
SIN.EQRPT868XT – User Guide Rev. 1.6 2. SIN.EQRPT868XT TECHNICAL SPECIFICATIONS SIN.EQRPT868XT is a repeater and receiver for W. M-Bus devices. The device’s main technical specifications are given below: Operating Temperature: [-20..+55°C] • Storage Temperature: [-25..+85°C] • Ingress Protection: IP40 (EN60529) •... -
Page 5: Aspect Of The Sin.eqrpt868Xt
SIN.EQRPT868XT – User Guide Rev. 1.6 3. ASPECT OF THE SIN.EQRPT868XT 3.1 Description of the SIN.EQRPT868XT The devices uses a technology that allows you to expand the W. M-Bus networks, in fact, between them, the antennas will automatically establish the connection that allows the best signal quality and, upon receipt of the W. -
Page 6: Sin.eqrpt868Xt Device
SIN.EQRPT868XT – User Guide Rev. 1.6 3.2 SIN.EQRPT868XT device Below find an image of the SIN.EQRPT868XT device with indications regarding its operational parts: A. Cables compartment lid B. LED Figure 2 – View of RPT868XT Figure 3 – Connections/buttons/LEDs 1. 100..240Vac power supply input (screw clamps) 2. -
Page 7: Repeater Configuration Through Keys Functions
SIN.EQRPT868XT – User Guide Rev. 1.6 4. REPEATER CONFIGURATION THROUGH KEYS FUNCTIONS 4.1 Change ID MESH The SIN.EQRPT868XT is considered installed and correctly powered.. If blue led (9) flashes for more than 5 minutes If blue led (9) remains fixed access after a few minutes 1. -
Page 8: Activate Snd_Ir Mode (Installation Mode)
SIN.EQRPT868XT – User Guide Rev. 1.6 4.2 Activate SND_IR mode (Installation Mode) a) It typically involves the installation of the AMR system and subsequently the installation of the heat cost allocators b) Both the AMR system and the distributors must be configured to work in this mode c) SND_IR mode activation procedure on a newly installed SIN.EQRPT868XT 1. -
Page 9: Accept Mode Activation All - Sin.eqrpt868Xt
SIN.EQRPT868XT – User Guide Rev. 1.6 4.3 Accept mode activation ALL - SIN.EQRPT868XT a) It is used when the commissioning is carried out after with respect to the installation of the heat cost allocators b) To activate the accept ALL mode on a newly installed SIN.EQRPT868XT 1. -
Page 10: Sin.eqrpt868Xt - S, T, C+T, S & C+T Mode Of Operation Modification
SIN.EQRPT868XT – User Guide Rev. 1.6 4.4 SIN.EQRPT868XT – S, T, C+T, S & C+T Mode of operation modification The SIN.EQRPT868XT is considered installed and correctly powered. 1. Press keys 2 and 3 simultaneously (t > 6s.) during the simultaneous pressing of keys 2 and 3, the green LEDs (8.1) and (8.2) will flash every ─... -
Page 11: Restore Factory Settings
SIN.EQRPT868XT – User Guide Rev. 1.6 4.5 Restore factory settings 1. Press and hold keys 2 and 3 simultaneously. 2. Then press the reset button 4, without releasing the keys 2 and 3 3. As soon as all the LEDs (8) and (9) flash quickly, release all three keys. S I N A P S I S . -
Page 12: Wall Mounting And Passing Of Cables
SIN.EQRPT868XT – User Guide Rev. 1.6 5. WALL MOUNTING AND PASSING OF CABLES Before making any connection, remove the power supply, complete the wiring, close the lid of the device and the power the Repeater. Figure 4 - wall mounting and passage of cables 1. -
Page 13: Usb Connection To The Pc, Connection Via Radio To The Sin.eqrtu1T And Positioning
SIN.EQRPT868XT – User Guide Rev. 1.6 6. USB CONNECTION TO THE PC, CONNECTION VIA RADIO TO THE SIN.EQRTU1T AND POSITIONING Figure 5 - Connections 1. Fix the SIN.EQRPT868XT repeater on fastening wall at minimum distance of 20 cm from the ceiling and from the adjacent wall. -
Page 14: Configuration Of The Repeaters Network
SIN.EQRPT868XT – User Guide Rev. 1.6 7. CONFIGURATION OF THE REPEATERS NETWORK 1. Place the Smart Repeaters SIN.EQRPT868XT following the instructions in CHAP.5, to ensure radio coverage of the various W. M-Bus transmitters installed that you want to obtain. 2. Power SIN.EQRTU1T, wait to boot, connect to the web interface and start scanning antennas and devices following the product manual. -
Page 15: Troubleshooting
SIN.EQRPT868XT – User Guide Rev. 1.6 8. TROUBLESHOOTING 1. The device does not switch on: In the event of mains power supply, check there is voltage present • If a USB port is used, check the quality of the USB cable and that the PC can supply a 500mA •...
