Digifobpro - Device Instructions
Filtering: The data is split into categories; Information, Infringement, Summary
and Latest . Turn ON or OFF options by highlighting using the UP and DOWN
arrows and turning an option ON or OFF with the Left or Right buttons.
First level Driver Card Analysis icons
Latest
Summary
Infringement
Information
Second level Driver Card Analysis icons
Drive
Rest
All modes; Drive, Rest, Work, POA.
Work
Availability
Time overlap
Third level Driver Card Analysis icons
Weekly
2 Weekly
Within 24 Hours.
Break
Digifobpro User Instructions
Putting analysis icons together:
The three levels of icon used in the driver card analysis are put together to give
an at a glance view of summarised data. For example;
You can scroll through all analysis entries and drill down with the OK button for
more detailed information.
Additional Driver Card Functions
Events and Faults Icons applicable to Driver Cards and Vehicles
Page - 6 Digifobpro User Instructions
= Latest summary for all modes in last 24 hours.
= Infringement - Rest - Weekly (Weekly rest infringement)
Activity data in Events and Faults
graphical form.
Vehicles Used Delete File - use
this cautiously!
General events
Faults (Recording Equipment)
Security breach event
Sensor Security Breach
Overspeeds
