740B Clifty Drive • Madison, Indiana 47250 • 812-574-7777
Item Description
A
Upper A-Arm, Right
B
Upper A-Arm, Left
C
Lower A-Arm, Left
D
Lower A-Arm, Right
(Left)
Read instructions and view illustrations before beginning.
Need help with your installation?
sales@superatv.com
1-812-574-7777
Thank You
© 2013 SuperATV.com. All Rights Reserved.
Qty
1
1
1
1
B
C
(Kit contents continue on following page)
www.superatv.com
8:00am - 9:00pm EST M-Th
8:00am - 7:00pm EST Friday
9:00am - 2:00pm EST Saturday
For Choosing
INSTALLATION INSTRUCTIONS
Polaris Ranger XP900 A-Arms
Item Description
E
Tie Rod Ends
F
Zerk Fittings
G
Brake Line Clamps
H
M5-.8 x 13mm Lg. Machine Screws
Liability Statement
SuperATV's products are designed to best fit users ATV/UTV under stock conditions.
Adding, modifying, or fabricating any factory, or aftermarket, parts will void any
warranty provided by SuperATV and is not recommended. SuperATV's products
could interfere with other aftermarket accessories. If user has aftermarket products
on machine, contact SuperATV to verify that they will work together.
Although SuperATV has thousands of satisfied customers, user should be aware
that installing lift kits, long travel, or suspension kits, tires, etc will change the ride
of machine and may increase maintenance and part wear. Operating any off-road
machine while, or after, consuming alcohol and/or drugs increases risk of bodily
harm or death. No warranty or representation is made as to this product's ability to
protect user from severe injury or death. SuperATV urges operators and occupants
to wear a helmet and appropriate riding gear at all times.
By purchasing and installing SuperATV products, user agrees that should damages
occur, SuperATV will not be held responsible for loss of time, use, labor fees,
replacement parts, or freight charges. SuperATV, nor any 3rd party, will not be held
responsible for any direct, indirect, incidental, special, or consequential damages
that result from any product purchased from SuperATV. The total liability of seller to
user for all damages, losses, and causes of action, if any, shall not exceed the total
purchase price paid for the product that gave rise to the claim.
SuperATV will warranty only parts provided by SuperATV. Any damage or problems
with OEM housings, bearings, seals, or other manufacturers products will not be
covered by SuperATV. SuperATV parts and products are not warrantied if item was
not installed properly, misused, or modified.
A
(Right)
D
Rev IN-AA-P-RAN900-13 12/17/2013
Qty
2
6
4
4
Advertisement
Table of Contents
Related Manuals for SuperATV Ranger XP900 A-Arms
Summary of Contents for SuperATV Ranger XP900 A-Arms
- Page 1 By purchasing and installing SuperATV products, user agrees that should damages 9:00am - 2:00pm EST Saturday occur, SuperATV will not be held responsible for loss of time, use, labor fees, replacement parts, or freight charges. SuperATV, nor any 3rd party, will not be held...
- Page 2 (Kit contents continued) Item Description Tie Rod Ends Zerk Fittings Brake Line Clamps M5-.8 x 13mm Lg. Machine Screws M5 x 13mm Lg. PHMS...
- Page 3 3. Transfer stock Bushings and Grease fittings into new A-Arms. See Fig. 1. For a starting point, adjust Upper A-Arms (A)(B) included Ball Joints as shown in Fig. 1a. 4. Use stock hardware and install A-Arms (A)(B)(C)(D) to Frame. SuperATV recommends using Loc-Tite on Nuts when installing. See Fig. 2.
- Page 4 (installation illustrations continued) Face of Nut to Ball Joint: 45mm Fig. 1a SuperATV recommends using Loc-Tite on Nuts when installing A-Arms to Frame. Install A-Arms to Frame with Stock Hardware Brake Line (Passenger Side) Fig. 2 Route Brake Lines so that no interference can occur. Secure with Brake Line Clamps (G) and M5-.8 x 13mm Lg.
- Page 5 Steering Stop Installation Note: Driver Side installation is shown. 1. Unclamp and slide Boot away from Steering Gear Box. 2. Install Steering Stop Bushing (A) onto shaft and slide until flush with outside of Steering Gear Box. See Fig. 1. 3.
- Page 6 Stock CV Guard Installation 1. Place stock CV Guard against Lower A-Arm (center tab on CV Guard with Cross Tube on Lower CV Guard) and mark hole locations onto Lower A-Arm. 2. Drill holes for Ø3/16” rivets and secure CV Guard to Lower A-Arm. Ensure that no interference can occur with Upper A-Arm or other components.
