- Page 1 instructions...
-
Page 3: Table Of Contents
Contents Welcome Setup options Warning foc.us dock & What you need to software understand before Intended use using foc.us Bluetooth® What’s in the box connection Before starting Troubleshooting Getting started Specifications Calibrate your Support foc.us Glossary Programs Starting & Stopping Warranty &... -
Page 5: Welcome
Welcome The foc.us v2 is an advanced micro current signal generator. Download the latest version of this manual from: http://www.foc.us/v2/downloads foc.us is designed to be used by healthy adults who do not suffer from epilepsy, brain or mental health conditions or have a metalic implant such as a skull plate, cochlear implant, pace-maker or others. -
Page 6: Warning
Warning If you suffer from epilepsy, seisures, brain lessions, bipolar depression or severe heart disease you should not use the foc.us headset. If you experience short term negative effects WARNING with foc.us you should immediately stop using it. This is not a toy and is not... - Page 7 If using your own electrodes it is not recommended to create novel electrode placements. Do not position the electrodes so that the current may pass through the brainstem. Do not position the electrodes over cuts, grazes or damaged skin. Allow at least 48 hours between usage. Always use the electrodes with wet sponges.
-
Page 8: What You Need To Understand Before
What you need to understand before using foc.us foc.us is designed to improve your mental gaming skills. You are exciting and inhibiting sections of your pre-frontal cortex with an electric current. Possible side effects include tingling sensations under the electrodes or on the scalp, visual artifacts, nausea, headaches and fatigue. - Page 9 Redness may appear under electrodes after use which will disappear after a short time. Foc.us should not be used during any activities other than seditary gaming. If you see white flashes, or phosphenes you should adjust the position of the headset on your head, pushing it further back away from your eyes.
-
Page 11: What's In The Box
What’s in the box 1. foc.us v2 2. foc.us dock 3. micro-usb cable for recharging 4. this instruction booklet... -
Page 13: Before Starting
Before starting Firmly push the v2 into the provided dock and connect the dock to a USB power supply to recharge. Install the foc.us software and check for firmware updates. http://www.foc.us/v2/downloads... - Page 15 Getting starting Wake the foc.us v2 by pressing the blue joystick and holding to turn on. Connect a compatible “Made for foc.us” headset. A list of compatible headsets can be found here: www.foc.us/made-for-focus...
-
Page 17: Calibrate Your
The calibration function allows you to find a current level that is comfortable for you. Start the calibrate function and follow the on-screen instructions. You can recalibrate your foc.us at any time by entering the calibrate menu. Ensure sponges are wet before use. - Page 18 Screen blue joystick click to select...
-
Page 19: Foc.us
Programs A program is a combination of settings used during a session. Foc.us ships with two programs - Gamer and Endurance You can create your own program with custom settings. Your calibration settings will override any program settings... -
Page 21: Starting & Stopping
Starting & Stopping a Session A program is a combination of settings used during a session. Foc.us ships with two programs - Gamer and Endurance You can create your own program with custom settings. Your calibration settings will override any... -
Page 22: Setup Options
Airplane mode - turns off bluetooth PIN - the default PIN is 000000 Reset - reset your foc.us device to factory settings Security - please set your foc.us device to lock to prevent un-authorised usage. - Page 23 Language - if your language is not supported please contact help@foc.us Session - foc.us+ session sharing settings Warnings - it is not recommend to use your foc.us more than once every 48 hours.
-
Page 25: Foc.us Dock
& software The foc.us dock and software can be used to update the firmware of your v2. It can also be used to sync your program and session data with foc.us+... -
Page 26: Intended Use
Intended use Use foc.us in accordance with the guidelines of the connected headset WARNING: If you attach external electrodes, make sure you know what you are doing. You have a responsibility to ensure they are not placed in positions that could be dangerous including but not limited to passing current through the brain stem. -
Page 27: Bluetooth® Connection
Bluetooth® connection foc.us can be controlled by bluetooth. Approved apps can be found here: http://www.foc.us/v2/apps Troubleshooting Problem Solution Cannot turn on Ensure battery is charged by placing in dock Error mode Ensure sponges are wet Battery will not Check connection of charge source. -
Page 28: Specifications
Weight: 21g Battery: 3.7V Li-Po 180mAh rechargable Max current: 2.05mA Max voltage: 60V Bluetooth: 4.0 bluetooth low energy GATT profile FCC ID: 2AAH6NUFC9 Applied part (BF) Support More information is available on the website: http://help.foc.us/ you can also email help@foc.us... -
Page 29: Glossary
Glossary Activate start the current flowing Activat between the electrodes Anode Anode positive electrode Cathod Cathode negative electrode Montag Montage the positioning of electrodes tDCS tRNS tDCS transcranial Direct Current Phosph Stimulation Sedent tRNS transcranial Random Noise Stimulation Phosphenes visual artifacts Sedentary sitting, not physically active... - Page 30 Constan current, max 2.0mA at 29K Ohms Supports 1 anode and 1 cathode Maximum DC output 58V, user configurable Qualified Accessoriess foc.us EDGE - 2 x 10cm 2 nickel plated electrodes - arm and head placement - use before training foc.us GAMER...
- Page 31 Cleaning and maintenance Clean with a dry cloth Battery should not be serviced. Opening the device voids the warranty. Equipment providing body floating protection against electric shock. Simultaneous connection of a patient to a h.f. surgical equipment may result in burns at the site of the stimulator electrodes and possible damange to the stimulator.
-
Page 32: Fcc
FCC warning statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 33: Warranty & Guarantee
Warranty & Guarantee foc.us warrants the foc.us headset (the “Product”), and only the Product, against defects in materials and workmanship under normal use for a period of twenty... - Page 34 Product will be uninterrupted or error-free. Limitation of remedies Under this Limited Warranty, foc.us liability...
- Page 35 Product by foc.us or its authorized service centers. A replacement Product or part assumes the remaining warranty of the original Product or Ninety (90) days from the date of replacement or repair, whichever is longer.
- Page 36 Limitation of damages In no event will foc.us or any of its affiliated or subsidiary companies be responsible for any special, incidental, or consequential damages resulting form the use of this Product, or based on any breach of warranty, breach of contract, negligence, tort or any other legal theory.
- Page 37 This Limited Warranty is valid only in the the United States and Europe for Products sold in the United States and Europe. Resellers, agents, or employees of foc.us are not authorized to make any modification, extension, or addition to this Limited Warranty.
- Page 38 www.foc.us...
