White - 4ft6 Bed with Slats
Assembly Instructions
Dimensions
208,2 cm
Width - 148cm
121,2 cm
Depth - 204cm
Height -109cm
112,9 cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
T1050-02 NR501-V6/V8
- Uno S Midsleeper
- Please keep for future reference
Batch nr:
Ladder can be fitted
right or left side
T1050-02
6564942
0844 8008475
Issue 1 - 22/10/10
Issue 1 - 25/11/14
1 of 13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Uno S Midsleeper and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stompa Uno S Midsleeper

  • Page 1 White - 4ft6 Bed with Slats - Uno S Midsleeper Assembly Instructions T1050-02 6564942 - Please keep for future reference Ladder can be fitted right or left side Dimensions 208,2 cm Width - 148cm 121,2 cm Depth - 204cm Height -109cm...
  • Page 2 IMPORTANT, READ CAREFULLY - RETAIN FOR FUTURE REFERENCE IMPORTANT, READ CAREFULLY - RETAIN FOR FUTURE REFERENCE • The bunk bed meets the european EN 747-1:2012 standards for security and durability. · Warning! Children can become trapped • The bunk bed meets the Bunk Beds between the bed and the wall.
  • Page 3 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Conformat screw Ø7x 60mm Screw 3.5 x 35mm Dowel Ø8x40 M6x10x13 Cross dowel x 4 M6x75 Bolt x 4...
  • Page 4 Components - Panels Components 1 Bed rail x 1 (200,6x14,5x2 cm) 10 Bed rail x 1 (200,6x14,5x2 cm) 6 Bed safety rail x 1 (200,6x14,5x2 cm) 4 of 13...
  • Page 5 Components - Panels 5.2 Slats x 1 5.1 Slats x 1 7 Front safety rail x 1 (164x14,5x2 cm) 2 End rail x 2 (80,2x40,4x1,9 cm) 3 Leg x 2 4 Leg x 2 8 Step x 3 (36x11,5x2,5 cm) 9 Ladder side x 2 (109x9x3,8 cm) (109x9x3,8 cm)
  • Page 6 7x60 Screw x 4 8x40 Wooden dowel x 20 Glue x 1 6 of 13...
  • Page 7 D=35 Sector x 4 D35 Cover Cap x 4 8x40 Wooden dowel x 15 7 of 13...
  • Page 8 D15x18 Cover Cap x 4 M6x75 Bolt x 2 M6x10x13 Cross dowel x 2 6,3x70 Screw x 2 M6x75 Bolt x 2 M6x10x13 Cross dowel x 2 D15x18 Cover Cap x 2 8 of 13...
  • Page 9 7x50 Screw x 12 D4x13 Cover Cap x 12 Left or Right 9 of 13...
  • Page 10 Max. mattress height! D15x18 Cover Cap x 1 6,3x70 Screw x 1 55/12,5x5(Zn) x 4 5x38 (Zn) Screw x 1 3,5x40 Screw x 30 10 of 13...
  • Page 11 D8x13 Cover Cap x 3 11 of 13...
  • Page 12 Fax: Please complete the enclosed Service Form and fax to 0560 1132071 By post: Please complete the enclosed Service From and post to: Nordika Design Ltd. t/a Stompa High Rigg Panorama Drive Ilkley, LS29 9RA We will do our utmost to supply spare parts within 7-10 working days of receipt of request.
  • Page 13 13 of 13 Page 9 of 9...
