RAB VAN GARAGE LIGHTER Installation Instructions Manual

Thank you for buying RAB lighting fixtures. Our aim is to design the best quality products so you can get the job done right.
We'd like to hear your comments. Call us at 888-RAB-1000, attention Marketing Department.
IMPORTANT
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
RAB Vandalproof fixtures must be wired in accordance with
the National Electrical Code and applicable local codes.
Proper grounding is required for safety.
WARNING: Make certain power is OFF before installing or maintaining fixture.
LOCATION
Fixture should be ceiling mounted. Fixture should not be recessed.
MOUNTING
Junction Box Mounting:
1. Remove refractor and reflector from fixture.
2. Remove close-up plug in back (see mounting note
below).
3. Connect fixture leads to supply leads with wire nuts.
4. Install reflector, install lamp and replace refractor.
MOUNTING NOTE: It is recommended that fixture be
attached securely by drilling through knockouts in back of
fixture and attaching to mounting surface (hardware not
supplied).
When drilling fixture, care must be taken to avoid drilling close to ballast or within 1/4" of sides of fixture. All unused entries
must be plugged. Use weatherproof silicone sealant to insure proper seal.
TAMPERPROOF SCREWS
RAB Vandalproof fixtures are shipped with both standard
screws and tamperproof screws.
VAN GARAGE LIGHTER
Installation Instructions
RAB Vandalproof fixtures should not be used in areas with
limited ventilation or high ambient temperatures. Installation
should be done by a qualified electrician.
Conduit Mounting:
1. Remove refractor and reflector from fixture.
2. Remove close up plug(s) in housing for desired conduit
entrance (see mounting note below)
3. Connect fixture leads to supply leads with wire nuts.
4. Install socket mounting plate, install lamp and replace
refractor.
For maximum security, insert tamperproof screws into the
refractor and tighten with Center Pin Torx screwdriver (catalog
#Vandriver, not supplied).
(over)
®
