BEDIENUNGSANLEITUNG
// INSTRUCTION MANUAL
CRIMPZANGE
080.000.051.000.000
Batteriefach
Battery compartment
Taster „ON/OFF" und „MODE"
"ON/OFF" and "MODE" buttons
Anzeige
//
Display
Crimpstelle
//
Crimping point
8-PUNKT-CRIMPZANGE MIT DIGITALANZEIGE
LEITUNGSQUERSCHNITTE 0,08–2,5 mm
Die 8-Punkt-Crimpzange wird zum Vercrimpen von gedrehten
Kontakten mit einer Leitung verwendet. Dabei verfügt die
Handcrimpzange zur Crimpmaßeinstellung über eine beson-
ders bedienerfreundliche Digitalanzeige. Das ergonomische
Design und die optimale Kraftübersetzung sorgen für komfor-
tables Arbeiten.
Die Zange eignet sich für einen maximalen Querschnittsbe-
reich von 0,08 (AWG28) bis 2,5 mm
kann je nach Produktserie abweichen.
Genauere Crimpinformationen sind dem Abschnitt „Werkzeuge
und Zubehör" des jeweiligen Produktkatalogs zu entnehmen.
SICHERHEITSHINWEISE
•
Crimpwerkzeuge erzeugen eine sehr hohe Presskraft.
Bei unsachgemäßer Handhabung kann dadurch
erhebliche Quetschgefahr bestehen!
•
Arbeiten unter Spannung sind nicht zulässig!
•
Bei Fragen kontaktieren Sie bitte den Hersteller.
Mehr Informationen auf www.odu.de
Further information at www.odu-connectors.com
// CRIMPING TOOL
//
//
2
(AWG28–13)
2
(AWG13). Dieser Bereich
Stellrad zur Crimpmaßeinstellung
Crimp setting adjustment wheel
Öffnung für Notentriegelung
Access to the emergency release lever
Positionierer (optional)
//
Positioner (optional)
8-POINT CRIMPING TOOL WITH DIGITAL DISPLAY
CABLE CROSS-SECTIONS 0.08–2.5 mm
The 8-point crimping tool is used to crimp turned contacts on
to a conductor. The special features of the hand-crimping tool
are a user-friendly display, ergonomic design and an optimum
force transmission for comfortable working.
The crimping tool is suitable for a maximum cross-section
range from 0.08 (AWG28) up to 2.5 mm
may differ depending on the product series.
More detailed crimp information can be found in the chapter
"Tools and Accessories" of the respective product catalog.
SAFETY INSTRUCTIONS
•
Crimping tools generate a very high pressing force. Incorrect
handling may result in considerable risk of crushing!
•
Working under voltage is not permitted!
•
For questions, please contact the manufacturer.
//
//
2
(AWG28–13)
(AWG13). This range
2
[003.003.000.000.012 | 30000205]
2018/05
