- Page 1 Microsemi 9501GO-ET 1-Port, 802.3at Outdoor PoE Midspan User Installation Guide...
- Page 2 Notice It is Microsemi’s policy to improve its products as new technology, components, software, and firmware become available. Microsemi, therefore, reserves the right to change specifications without prior notice. Technical Support If you encounter problems when installing or using this product, please consult the Microsemi website at: http://www.Microsemi.com.
-
Page 3: Product Overview
Product Overview Microsemi PD-9501GO-ET is a 1-Port 802.3at Gigabit PoE Outdoor Midspan that offers a cost effective, IEEE 802.3atTM compliant solution, guaranteeing 60 Watts of power and ensures safe and reliable operation in outdoor environments for standard PoE data terminal. The PD-9501GO-ET supports 10/100/1000Mbps data rates... - Page 4 AC main power source. PoE Midspan AC power lines should be connected to the socket- outlet that shall be installed near the equipment and be easily accessible. Copyright 2017 Microsemi Page 4 PD-9501GO-ET One Enterprise Aliso Viejo, CA 92656 USA...
-
Page 5: Product View
Step1: Connect the chassis bolt to earth ground. USE A TORQUE OF 10Lb-in (1.1Nm) - 15Lb-in(1.7Nm) CONNECT TO FOR TIGHTENING THE NUT EARTH GROUND Figure 2 Copyright 2017 Microsemi Page 5 PD-9501GO_ET One Enterprise Aliso Viejo, CA 92656 USA... - Page 6 Step 2: There are two options for the installation of PD-9501GO-ET: Wall installation – PoE Midspan unit can be mounted on a wall/bench (all kind of flat surfaces: wood, brick, concrete etc.) using the mounting holes. Pole installation - using optional mount kit (sold separately).
- Page 7 Step 2B Pole installation using optional mount kit (sold separately) Warning: Mounting bracket must be connected to earth ground! Copyright 2017 Microsemi Page 7 PD-9501GO_ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 8 Step 3A: Pole of 1” (25.4mm) < ø < 3” (76.2mm) Copyright 2017 Microsemi Page 8 PD-9501GO-ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 9 Step 3B: Pole of- 3” (76.2mm) < ø < 8” (203.2mm) Insert Screwdriver, press and rotate counter-clockwise to unlock Pull cap away from unit Copyright 2017 Microsemi Page 9 PD-9501GO_ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 10 Push Housing into Body according to lead rails Lead Rails Click Insert Seal and Clamp spring into body, then tighten the nut using 4N•m torque Figure 4 Copyright 2017 Microsemi Page 10 PD-9501GO-ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 11 Note: Please use outdoor certified cable with thickness diameter of 4-8mm STEP-1 STEP-2 STEP-3 STEP-4 STEP-5 FASTEN TIGHTLY BY HAND STEP-6 FASTEN TIGHTLY BY HAND Figure 5 Copyright 2017 Microsemi Page 11 PD-9501GO_ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 12 For non AF/AT compliant unit - use a splitter; ensure splitter is connected close to the terminal and not on the Midspan. This unit is designed for outdoor use. Copyright 2017 Microsemi Page 12 PD-9501GO-ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 13 (non-crossover) cabling, with all four pairs. data link 11. Verify Ethernet cable length is less than 100 meters from Ethernet source to the remote terminal. Copyright 2017 Microsemi Page 13 PD-9501GO_ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 14 Measures must be taken to prevent physical damage to the power supply cord, including proper routing. Copyright 2017 Microsemi Page 14 PD-9501GO-ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 15 If you purchase a replacement product, hand your complete old product back to the retailer. He should accept it as required by the national WEEE legislation. Copyright 2017 Microsemi Page 15 PD-9501GO_ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 16 Ethernet 10/100/1000Base-T, voltage on wire pairs: (-)1-2, plus 54VDC 7-8 & (+)3-6, 4-5 3 Pins AC power in – Line, AC Power IN Neutral and Earth Ground Copyright 2017 Microsemi Page 16 PD-9501GO-ET One Enterprise Aliso Viejo, CA 92656 USA...
- Page 17 CONFIDENTIAL information of Microsemi and cannot be copied, published, uploaded, posted, transmitted, distributed or disclosed or used without the express duly signed written consent of Microsemi. If the recipient of this document has entered into a disclosure agreement with Microsemi, then the terms of such Agreement will also apply.
