Typ 8650
AirLINE Ex
Electrical and Pneumatic Automation System
Quickstart
THE QUICKSTART
CAUTION!
The quickstart has to be read and understood.
• Read the quickstart through carefully. Pay attention in
particular to the chapters General Safety Precautions
and Intended Use.
The Quickstart will enable you to install the system.
You will find more detailed information in the op-
erating instructions on the
Internet under:
www.buerkert.com
→ Technical Data → manuals →
type 8650
Trademarks
ET 200iSP™ Siemens AG
PROFIBUS
PROFIBUS Nutzerorganisation e. V.
®
2
We reserve the right to make technical changes without notice.
Technische Änderungen vorbehalten.
Sous resérve de modification techniques.
© Bürkert Werke GmbH & Co. KG, 2007 - 2017
Operating Instructions 1806/02_EU-en_00805635
www.burkert.com
SCOPE OF SUPPLY
Immediately upon receipt of delivery, check that the
contents have not been damaged and that the delivery
matches the delivery note or packing list in type and scope.
Please contact us immediately in the event of discrep-
ancies.
Germany
Contact Address:
Bürkert Fluid Control Systems
Sales Center
Chr.-Bürkert-Str. 13-17
D-74653 Ingelfingen
Tel. : 07940 - 10 111
Fax: 07940 - 10 448
E-mail: info@de.buerkert.com
International
Contact addresses are found on the final pages of this
operating manual.
You can also find information on the Internet under:
www.buerkert.com
Bürkert
tions
Company
Loca-
3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Burkert AirLINE Ex 8650
Summary of Contents for Burkert AirLINE Ex 8650
- Page 1 We reserve the right to make technical changes without notice. Technische Änderungen vorbehalten. Sous resérve de modification techniques. © Bürkert Werke GmbH & Co. KG, 2007 - 2017 Operating Instructions 1806/02_EU-en_00805635 www.burkert.com Quickstart THE QUICKSTART SCOPE OF SUPPLY Immediately upon receipt of delivery, check that the...
-
Page 2: Intended Use
SYMBOLS INTENDED USE Safety Precautions WARNING! DANGER! The device may only be used for the applications indicated in chapter System Description AirLINE Ex High risk! of the operating manual and only in conjunction with signifies an immediate impending danger. If it is not third-party devices or components recommended or avoided, death or serious injury will result. -
Page 3: System Description
SYSTEM DESCRIPTION Power supply! The device may only be operated with direct current. Other- General technical data wise damage may be caused to the system. Media clean, dry air (oiled / unoiled) Ensure that the device is connected only to a DC neutral gases (particle size max. - Page 4 Supply slice Technical data Power consump- 0 W (Module is electrically pas- tion sive) Pneumatic G 3/8“, G 1/8“ connections or NPT 3/8“, NPT 1/8“ Dimensions Appr. 50 (per station 44) x 190 x 120 mm Material (housing PA, PBT, PC pneumatic) Weight 480 g / 520 g...
- Page 5 Pneumatic power data Switching times [ms]: measured in accordance with ISO 12238 These values may differ, depending on the valve type and Valve type function (see operating manual, chapter Configuration and Function of the Modules / Integratable Valves) Pressure data [bar]: Overpressure with respect to atmospheric pressure Connection variants on request Circuit functions...
- Page 6 Basic pneumatic module Pneumatic connections Possible configuration of the working ports Position Valves Double valve 3/2-way 5/2-way 2x 3/2-way 6524/6526 6525/6527 6524/6526 not used 2 (valve 12) 4 (valve 14) Illustration: Basic pneumatic Pneumatic connections on the valve slice module for valves with stacking size 28 Check valve (opt.) 30 Flange for valve...
- Page 7 Terminal Elektronic module module Illustration: Terminal module 32 Hinge contour for the electronic module 18 Power-Bus 20 Communication bus 33 Abutment for the electronic module 34 Plug for the electronic module 15 Unlocking slide (only with ID no. 173 369) Illustration: not with ID no.
-
Page 8: Installation
Pneumatic valve type 6526/6527 INSTALLATION Technical data Safety Precautions Stacking size 16.5 mm DANGER! Material PA (Housing) hazard due to high pressure! Gasket material NBR Interference with the system will result in an acute risk dry compressed air, oiled or oil-free of injury. - Page 9 Tools and torques Removing /hooking a preassembled system from an S7 profile rail Application Type and size of Torque the tool Actuation of the locking Plain screwdriver, elements size 5 Screwing on the clamping Plain screwdriver, 1.3 ... bolts onto the supply size 7 1.5 Nm modules,...
- Page 10 Conversion, expansion and assembly of Removal of individual slices an existing system with individual slices Supply slice → Release the desired module 19 Inclined tie rod by actuating the locking element and swing out the module. → Note in the case of the pres- sure gauge module that the Illustration: hose has to be disconnected...
- Page 11 → Replacement of a terminal or pneumatic module Realing the pneumatic module on the terminal module. → Tighten the three screws again. Important note! • When converting or expanding the system, pay attention that the sal rings of the pneumatic modules are coated with a film of suitable grease (e.
- Page 12 Information on the Internet: Operating manual and data sheets on Type 8650 can be found on the Internet under: Shut down the system as follows: → www.burkert.com Technical data manuals / Depressurise the system. → data sheet Type 8690 Switch off the power supply.
-
Page 13: Packaging, Transport, Storage
PACKAGING, TRANSPORT, STORAGE DISPOSAL CAUTION! CAUTION! Transport damage! Environmental damage due to device components contaminated with media! Inadequately protected devices may be damaged • Observe the relevant waste disposal and environ- during transport. mental protection regulations. • Transport the device in a protective packaging to avoid moisture and dirt.
