- Page 1 Operating Manual Digital display unit M3605 with five limit contacts M3605 operating manual V1.01e...
- Page 2 Warranty Mostec warrants this product to be free of manufacturing defects for a 2-year period after the original date of purchase. Within this period, defective products will be repaired free of charge provided that the defect occurred during normal operation. This warranty does not cover damage to the product resulting from ordinary usage such as front panel scratches, broken control elements and corrosion, etc.
-
Page 3: Table Of Contents
Keyboard lock/unlock ......................10 Language setting ....................... 10 Customer label ........................10 Factory setting ........................10 Device info ........................10 6/6 ............................. 10 Contrast ..........................10 Factory Settings ........................ 11 Mechanical Dimensions ....................12 Technical Data ........................14 M3605 operating manual V1.01e... -
Page 4: Front Elements And Keyboard
2 value setup menu, direct display of limit contact 3 value setup menu, direct display of limit contact 4 value display the setup menu, input display the main menu, exit plus 5-12 minus 5-12 M3605 operating manual V1.01e... -
Page 5: Setup Menu, Setting The Limits Of The Instruments
B. Setup menu, setting the limits of the instruments The M3605 has 3 ways to change the limit values of the limit contacts. To make the handling of the instrument simple, we have made a direct entry into the cursor menu available. -
Page 6: User Menu
Rel1-5: turn off delay Rel1-5: hysteresis Rel1-5: label Time setup See section G USB settings Date setup Data log period Remove memory stick Keyboard lock/unlock See section H Instrument settings Language settings Custom label Factory setting Instrument info Contrast M3605 operating manual V1.01e... -
Page 7: Measurement Settings
Min: 4.0mA with (+) and (-) (ENT) to store and select the (ENT) to store and select the Max: 20.0mA with (+) and (-) Max: 20.0mA with (+) and (-) store and leave with (ENT) store and leave with (ENT) M3605 operating manual V1.01e... -
Page 8: Relay Settings
(+) and (-), possible resolution is 5 to 200 parts of range Relay 1-5: label Change characters with (+) and (-) and jump with (F3) and (F4) to the next character, confirm the label text with (ENT). M3605 operating manual V1.01e... -
Page 9: Usb Settings
04.07.2018 12:12:55 10.00 04.07.2018 12:13:03 10.01 04.07.2018 12:13:04 10.03 04.07.2018 12:13:06 10.15 04.07.2018 12:13:07 10.78 USB error code error description E: xx drive not formatted drive wrong formatted drive is write protected sector size not supported M3605 operating manual V1.01e... -
Page 10: Instrument Settings
Change the contrast with (+) able to move back to this item if and (-), confirm with (ENT) Contrast you select a contrast which makes the graphics on the screen invisible (too dark or too bright) M3605 operating manual V1.01e... -
Page 11: Factory Settings
Factory Settings (OEM factory settings can differ from the standard MOSTEC factory settings) Measuring settings: Input range display Min: 20.00% Input range display Max: 100.00% Display range Min: Display range Max: 1000 Decimal point display: XXX.X Unit display: “ %”... -
Page 12: Mechanical Dimensions
Rel 5: turn off delay Rel 5: hysteresis Rel 5: label “5 “ USB settings: Clock setup: Date setup: DDMMYY Log period: Device settings: Switch lock/unlock Language: English Custom label: all Blanks Contrast: Mechanical Dimensions Side view: M3605 operating manual V1.01e... -
Page 13: Rear View
Rear view: M3605 operating manual V1.01e... -
Page 14: Technical Data
Plug-in terminals on the back panel Weight: 304g Hardware: 2 quick-mounting clips 1 operating instructions Warranty: 2 years Other options: – special measuring range / signal output – customer functions, OEM customer home screen / logo – Transparent cover IP55 M3605 operating manual V1.01e...
