Mini Par UV LED
CAUTION! Please read and under-
stand these instructions before
installing or operating this unit.

Introduction:

The Mini Par UV LED has been tested at the factory, there is no assembly required. The unit is ready
to be plugged into a power outlet. This unit has 3 DMX channel modes; 4/6/8 channels. It has 6
operating modes; UV Dimmer mode, Jump change mode, Fade mode, Pulse change mode, Sound
Active mode, or DMX mode.
1 Year Limited Warranty:
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
Customer Support:
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Eliminator Lighting warranty is valid from the date of purchase. Our
Office: (323) 316-9706
Fax: 888-287-5224
Web: info@eliminatorlighting.com

SPECIFICATIONS:

Model:
Voltage:
LEDs:
UV Range:
Beam Angle:
Power Consumption:
Weight:
Size:
Working Position:
Duty Cycle:
DMX Channels:
Colors:
Warranty:
Caution! Never open unit when in use. Always
disconnect main power before replacing fuse.
Remember to always replace with the exact same
type fuse.
Mini Par UV LED
100V-240V 50/60Hz
12 x 1W UV LEDs
396-435nm
25 Degrees
14W
1lbs./ 0.5kgs.
153 x 145 x 95mm
Any Safe position
None
3 DMX Channel Modes:
4/6/8 Channels
UV
1 Year

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mini Par UV LED and is the answer not in the manual?

Questions and answers

Summary of Contents for Eliminator Lighting Mini Par UV LED

  • Page 1 Introduction: The Mini Par UV LED has been tested at the factory, there is no assembly required. The unit is ready to be plugged into a power outlet. This unit has 3 DMX channel modes; 4/6/8 channels. It has 6 operating modes;...
  • Page 2 RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET (UV) RADIATION! FIXTURE EMITS HIGH INTENSITY ULTRAVIOLET (UV) LIGHT AT A WAVELENGTH OF 396NM - 435NM. WEAR PROPER EYE AND SKIN PROTECTION. AVOID PROLONGED PERIODS OF EXPOSURE. AVOID WEARING WHITE COLOR CLOTHING AND/OR USING (UV) PAINTS ON SKIN.
  • Page 3 DMX Mode: Operating through a DMX controller gives the user the freedom to create their own programs tailored to their own individual needs. The Mini Par UVW LED has 3 DMX channel modes; 4/6/8 channels. See the chart below for the DMX traits and values. 1.
  • Page 4 0-15 No Function 16-75 ASC- 76-135 ACC- 136-195 FAde 196-255 SOUF 0-255 Speed/Sensitivity(SOUF) No Function 6-255 Flash(slow to fast) Eliminator Lighting 4295 Charter Street Los Angeles, CA 90058 USA Tel: (323) 316-9706 / Fax: 888-287-5224 Web: www.eliminatorlighting.com / E-mail: info@eliminatorlighting.com...
