Setup Manual
Suggested Specification
For
Model CG10, CG10A & CG10B
Beckett Gas Burners
R.W.
Beckett
Corporation
_________________________________________________________________________________________________________________________________________________________________________________________________________________
Mail: P.O. Box 1289, Elyria, OH 44036
|
Ship: 38251 Center Ridge Rd., North Ridgeville, OH 44039
|
Ph: (440)327-1060
|
Fax: (440)327-1064
Advertisement
Related Manuals for Beckett CG10A
Summary of Contents for Beckett CG10A
- Page 1 Suggested Specification Model CG10, CG10A & CG10B Beckett Gas Burners R.W. Beckett Corporation _________________________________________________________________________________________________________________________________________________________________________________________________________________ Mail: P.O. Box 1289, Elyria, OH 44036 Ship: 38251 Center Ridge Rd., North Ridgeville, OH 44039 Ph: (440)327-1060 Fax: (440)327-1064...
- Page 2 Air required for combustion shall be supplied by a blower, mounted integral to the burner. The blower wheel shall be of a forward curved “squirrel Cage” design and shall be directly driven by a 1/3HP, 3450rpm, _____volt, 60Hertz, ____Phase motor. The burner shall be equipped with an SPDT differential air pressure switch interlocked and continuously monitored to prevent burner operation if there is insufficient combustion air.
- Page 3 Liability Insurance with minimum coverage of $10,000,000. Burner Start up Information and Test Data: On completion of the burner system start up- the installing contractor will complete the attached “Burner Start Up and Test Data” form and deliver to the Specifying Engineer.
-
Page 4: Control Settings
Burner Start Up Information & Test Data Beckett Model ____________________ Job Location_____________________________________________________________ Start Up Date_____________ Company Name_________________ Technician Name________________ Type of Gas: NAT____ Propane____ Gas Pressure at Train Inlet Burner off position ______w.c Gas Pressure Train Inlet Light-Off ________w.c High Fire ________w.c Gas Pressure at Burner Light-Off ________w.c...
