Dispose of worn battery safely.
5.0 Cleaning and sterilization
The outer surface of the instrument may be cleaned
with a wet cloth, the remaining stains can be cleaned
off with a mixture of 50% alcohol and 50% distilled
water. Do not wipe with any corrosive detergent to
avoid damaging the surface.
Cleaning the lenses: Mirror-cleaning paper or a drop
of liquid solvent (50% alcohol and 50% ether) may be
used to clean the lens, blow it carefully. If there is dust
on the lens, blow them or brush them with a dust pen.
Illumination
> 22,000 lux @ 30 cm
LED Life
>40,000 hours
Color Temperature
4,000 °K
Color Rendition
92 Typical
Index (CRI)
Light Degradation
None
Spot Size
60 mm @ 300 mm working
distance
Intensity Range
3% to 100%
Operating Time
>10 hours typical at
maximum intensity
Normal Recharge
3.6 hours
Time
Quick Recharge
2 hours, for 8 hours of
Time
maximum intensity
Battery Charger
Universal: 100 to 264 VAC,
50 to 60 Hz.,8.4 VDC @ 1.3
A
Weight (headlight)
23 grams
Weight (Battery
190 grams
Pack)
4.25" x 2.7" x 1.1"
Size (control
unit/battery pack)
6.0 SPECIFICATIONS
IsoLux llc, 1045 Collier Center Way, Naples, Florida USA 34110 phone: 239 514 7475 fax: 239 514 7476
email:
info@isoluxllc.com
web:
www.isoluxllc.com
7.0 Symbols:
Internal electrical power source
Class Ⅱ
Attention: Read User's Guide for warnings
and cautions and instructions for use.
8.0 Warnings and Cautions
Warning: This product must not be used in the
presence of flammable gases.
Warning: This product should not be
immersed in fluids.
Warning: Do not shine the light directly into
the patient's eyes.
Warning: Ensure that the headband power
cord is located in the clips provided
9.0 List of Spare Components
Item
Qty.
Description
1
1
Clips, bag of 2
2
1
Power Pack (controller)
3
1
Safety Glasses
4
1
Yellow Filter
5
1
Battery Charger
Part No.
IL-2323
IL-2324
IL-2328
IL-2322
IL-2327
