1
CALIBRATION KIT FOR
EFT / BURST CAPACITIVE
COUPLING CLAMP
INA 3425
USER MANUAL
601-339A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INA 3425 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Teseq INA 3425

  • Page 1 CALIBRATION KIT FOR EFT / BURST CAPACITIVE COUPLING CLAMP INA 3425 USER MANUAL 601-339A...
  • Page 2 CALIBRATION KIT FOR EFT / BURST CAPACITIVE COUPLING CLAMP INA 3425 USER MANUAL Calibration kit for EFT / Burst Capacitive coupling clamp INA 3425...
  • Page 3: Table Of Contents

    Typical burst wave and parameters at generator output Typical burst wave and parameters at Coupling clamp output Technical data Technical parameters INA 3425 transducer plate technical parameters INA 3425 termination bracket (connecting adapter) 13 Accessory CAS 3025 Maintenance and warranty Maintenance and cleaning...
  • Page 5: Safety Instructions

    1 SAFETY INSTRUCTIONS INA 3425 calibration kit for EFT / Burst coupling clamp is an accessory to be used with IEC 61000-4-4 Burst generators and coupling clamps only. These type of instruments generate high voltage peaks up to 4 or even 8 kV.
  • Page 6 – but stays undangerous for the normal human being. TESEQ recommends the use of the safety cover with Interlock for all applications using genera- tors for more then 4 kV Burst pulses. Calibration kit for EFT / Burst Capacitive coupling clamp INA 3425...
  • Page 7: Description

    / EFT coupling clamps as specified in basic standard IEC 61000-4-4 Ed 3.0 : 2012 The INA 3425 consists in a transducer plate and a termination bracket (con- nection adapter) Fig. 1: INA 3425 transducer plate and termination bracket (connecting adapter)
  • Page 8: Preparation For Operation

    – Place the INA 3425 into the coupling clamp to be calibrated – position the whole as specified. Note that the Teseq sticker at the end of INA 3425 is placed the way that when in line with the end of the coupling clamp , the distances to the connecting adapter will automatically be <...
  • Page 9 - Connect the delivered HV pulse cable to the pulse output of the used EFT / Burst generator. As shown in Fig 3 Fig. 3: CDN 3425 connected to the EFT output of a NSG 3040 generator – Connect termination bracket (connection adapter) at the other end of the coupling clamp to calibrate as shown in Fig 4 Fig.
  • Page 10 – measure burst pulse waveshape and parameters at Coupling clamp output. – turn the Burst coupling clamp in the other direction in order to verify / calibrate the other path, and repeat the measurements. Calibration kit for EFT / Burst Capacitive coupling clamp INA 3425...
  • Page 11: Typical Waveform Data

    3 TYPICAL WAVEFORM DATA 3.1 Typical burst wave and parameters at generator output...
  • Page 12: Typical Burst Wave And Parameters At Coupling Clamp Output

    3.2 Typical burst wave and parameters at Coupling clamp output Calibration kit for EFT / Burst Capacitive coupling clamp INA 3425...
  • Page 13: Technical Data

    Dielectric sheets (top and bottom) 140 x 1070 x 0,5 mm Total thikness 1,5 mm Dielectris strength (isolation) 5 kV Weight 0.3 kg approx. 4.2 technical parameters INA 3425 termination bracket (connecting adapter) Input connector Banana Output connector SHV – fits for INA 265A (CAS 3025) – terminator/ attenuator...
  • Page 14: Accessory Cas 3025

    1 meter, RG 58, and of a traceable calibration certificate, a user manual and carring case. It is Full compliant to IEC 64000-4-4. Calibration kit for EFT / Burst Capacitive coupling clamp INA 3425...
  • Page 15: Maintenance And Warranty

    The warranty does not cover damages due to transportation, poor pack- aging, and those damages caused through use of the equipment for unforeseen purposes and the effects of physical force. 5.3 Shipping Always use original Teseq packaging, make sure the various warning labels for delicate instruments are well visible.
  • Page 16 T + 44 845 074 0660 F + 886 2 2917 2626 F + 44 845 074 0656 taiwansales @ teseq.com uksales @ teseq.com © July 2012 Teseq ® Teseq Inc. Specifications subject to change T + 1 732 417 0501 without notice.
