Quick Start Guide
Identix miniPad – rPad
This guide provides simple steps to quickly start using your new Identix miniPad,
miniPad SMA or rPad UHF RFID reader

Box Contents

•
1 Identix miniPad or miniPad SMA or rPad
•
1 mini USB cable
•
1 Quick Start Guide
•
May include tag samples
Identix miniPad
USB 2.0 connector
RGB LED
Embedded antenna
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the miniPad and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Identix miniPad

Summary of Contents for Identix miniPad

  • Page 1 Quick Start Guide Identix miniPad – rPad This guide provides simple steps to quickly start using your new Identix miniPad, miniPad SMA or rPad UHF RFID reader Box Contents • 1 Identix miniPad or miniPad SMA or rPad • 1 mini USB cable •...
  • Page 2 Identix rPad RGB LED USB 2.0 connector Embedded antenna The devices ship from Identix with the following default configuration: • Operating mode – HID - Keyboard wedge emulation • Transmission Power - 15dBm (may be increased further up to 23dBm) •...
  • Page 3 Utilities folder => then click on Terminal. • The Software Developers Kit (SDK) for the miniPad – miniPad SMA and rPad is available for download in the same location. The SDK is available for Microsoft .NET C#. For other programming languages, please contact Identix.
  • Page 4 1) Configure the miniPad / rPad reader to operate in HID Keyboard Emulation mode. 2) Open an application like Excel or Notepad. 3) Place UHF RFID tags on top of the miniPad or rPad embedded antenna. 4) See the tags reading results in the opened application. RAW Mode In this mode of operation, a simple host application controls the device.
  • Page 5 EPCs of the tags that are read by the device. Modifying the Device Configuration A configuration file (“Identix-Pad.cfg”) is stored inside a removable drive (labeled IDENTIX that mounts automatically when the device connects to the host computer), allows the user to switch between Transparent and HID Keyboard Emulation modes.
  • Page 6 To change the operation mode between Transparent and HID, edit the entry “Opmode” on the configuration file. After saving the configuration file, the device will automatically switch to the appropriate operating mode. All remaining configuration file entries are applicable when operating in HID Keyboard emulation mode only.
  • Page 7 Installing the miniPad – miniPad SMA - rPad USB Driver on Windows XP, Windows 7 and 8.x 1) Download the miniPad – miniPad SMA - rPad Windows USB driver file from https://idntx.zendesk.com 2) Connect the device to your PC using the mini USB cable provided.
  • Page 8 (“hazardous uses”) or for use in automotive environments. Customers must indemnify Identix against any damages arising out of the use of Identix products in any hazardous or automotive uses.
