Vertex EVX-Link Installation Manual

EVX-Link is a fast and easy way to connect multiple DMR digital coverage areas regardless of geography.
This system provides a seamless and reliable connection via the use of an existing Local Area Network (LAN) or
internet. It works with or without a repeater infrastructure which offers great flexibility.
EVX-Link can be used with existing systems or can replace the functionality of legacy high power repeater equip-
ment.
P
rograMMing thE
Install the Programming Software for the EVX-Link to your Windows
ing system) in advance.
Set up the EVX-Link, computer, eVerge transceiver and its DC power supply, as shown in illustration.
Turn on the eVerge transceiver in order to supply power to the EVX-Link.
Using the programming software, input the IP address information for the EVX-Link on your site, and the IP ad-
dress information for those EVX-Link system sites you wish to connect to.
When the EVX-Link programming is finished, disconnect the EVX-Link from the computer.
Windows
Note for US Users: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Note for European Users: This is a Class A product. In a domestic environment this product may cause ra-
dio interference in which case the user may be required to take adequate measures.
EVX-L
iP C
onnECt
i
nStaLLation
EVX-L
ink
® Computer
Micro USB - USB Connection Cable ( not supplied )
Vertex Standard LMR, Inc.
4-6-8 Shibaura, Minato-ku, Tokyo 108-0023, Japan
http://www.vertexstandard.com
ink
S
oLution
M
anuaL
® computer (Windows
Vertex Standard eVerge Transceiver
To Power Supply
EVX-Link
N U
RESET LAN USB BOOT SW RADIO
Supplied D-Sub Cable
( : refer to the installation manual )
