Firebird-Systems DCT411 Quick Start Manual

1. IMPORTANT GUIDELINES

REVIEW THIS GUIDE IN ITS ENTIRETY BEFORE INSTALLING YOUR DCT411 SET TOP BOX. FOLLOW
THESE INSTRUCTIONS BEFORE CALLING SUPPORT.

2. PREPARING FOR INSTALLATION

2.1 Unpacking

(A)

3. INSTALLATION

3.1 Connecting the Set-Top Box

Cable TV
Full Version Users Manual is at: http://www. Firebird-systems.com/graphics/dct411/DCT411-User-Manual.pdf
Rev. 043015
DCT411 Set Top Box
p/n
Quick Start Guide
Inspect the carton upon receiving and note any damage to the carton for possible unit damage.
Carton Includes:
(A) DCT411 Quick Start Guide
(B) DCT411 Unit
(C) Power Adapter
(D) HDMI Cable
(C)
(B)
- Remove power from the TV
- Connect the "Cable TV" cable to the "Cable In" connector on the set-top box (Figure 3.1)
- Connect the HDMI (D) or Video/Audio (E) cables to the set-top box and TV (Figure 3.2)
- Plug the TV into the power
- Plug the Power Adapter (C) into the set-top box and connect to the AC power outlet (Figure 3.3)
Figure 3.1
HDMI
- Change the source/input on the TV to either
HDMI or AV depending on how you connected
the TV to the set-top box
- The first time the set-top box is powered on it
will scan for the TV channels and show the
lowing screen (LEFT)
- Once the scan is completed, a display of de-
tected TV and Radio channels will appear. To
finish, press "OK" (RIGHT)
-After you have selected OK, you will be able to
view all detected channels on your TV
(E) Audio/Video Cables
(F) Remote Control
(G) Two (2) Batteries
(D)
Figure 3.2
Video/Audio
fol-
(F)
(E)
Figure 3.3
Power Adapter
(G)
