- Page 1 SANDBLASTER ORO PLUS MAINTENANCE AND INSTRUCTION MANUAL...
-
Page 2: Description Of The Machine
DESCRIPTION OF THE MACHINE The ORO PLUS is a compact, fully fitted sandblaster combining practical and ergonomic design to competitive price. ORO has been studied to remove investment particles as well as to carry out satin-finishing operations utilizing the suitable abrasive for use in the Dental, Gold and Jewellery field, thus emphasizing reliability and ease of use of such blasting unit. -
Page 3: Maintenance Instructions
INSTRUCTIONS FOR USE • Switch on light switch (34), if the dust extraction system connected to the machine is not automatically activated by the machine, always operate the filtering system before starting the blasting process. • Introduce the part to be blasted inside the working chamber and close the window locking pin (19 –... -
Page 4: Troubleshooting
TROUBLESHOOTING Problem: NO LIGHTING Possible cause Remedy Bad electrical connection. Check that the plug is correctly plugged in. Switch is damaged. Check the connections and operation (some dust could have entered inevitably oxidizing and seizing up contacts) - try to blow compressed air and eventually replace. - Page 5 TECHNICAL REFERENCE REGULATIONS AND TEST PROCEDURES The ORO sandblaster is mass-manufactured by DENTALFARM in compliance with technical and safety rules in force, as provided for by the 2006/42 CEE Community Directive on Machinery. Careful inspection and full routine testing is carried out singularly on each machine which is furtherly tested by an automatic test installation assuring compliance with the fixed limits.
- Page 6 EXPLODED DRAWING AND SPARE-PART LIST ORO PLUS (A1054S) CODE DESCRIPTION 1000534 COMPLETE LED LIGHTING SYSTEM 1072037 LIGHTING SYSTEM BASE 1072040 ELECTRONIC BALLAST 1072041 42 LED CIRCUIT 1072038 LIGHTING SYSTEM COVER RMBL028 HINGE PIN RCB016A HINGE (MOVABLE PART) RWA006 JOINT FOR FILTER FIXING FLANGE...
-
Page 8: Technical Specifications
LIGHT SWITCH ELECTRONIC BALLAST 42 LED CIRCUIT P OUT EXTRACTOR SOCKET PNEUMATIC CIRCUIT REF. DESCRIPTION FOOT-CONTROL BLASTING PROJECTOR DENTALFARM s.r.l. , 9/a - 10138 TORINO – ITALY Via Susa (+39) 011/4346632 - 011/4346588 - 011/ 4346366 e-mail: info@dentalfarm.it - sito: www.dentalfarm.it...
