LED Explanation

Power Main Secondary Wireless Signal
Power LED
On: The power on.
Main and Secondary LED
On: A device is connected to this port, but there is no activity.
Flashing: A device is connected to this port, and is active.
Wireless Signal LED
AP/AP Router mode: All four LEDs remain solid.
Client/Bridge/Repeater/AP Client Router mode:
The more LEDs lit will indicate the better wireless signal strength.
Power Main Secondary Wireless Signal
RESET Main GND
Secondary
