VJJT PanelBridge N5 User Manual

VJJT PanelBridge N5 User Manual

5ghz indoor/outdoor 20dbi cpe real throughput 160mbps+

Advertisement

www.v j j t.com
300
Mbps
OS
5
GHz
PanelBridge
5
5GHz lndoor/Outdoor 20dBi CPE
real throughput 160Mbps+
Default IP:192.168.1.88
username:v j j t
password:v j j t

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PanelBridge N5 and is the answer not in the manual?

Questions and answers

Summary of Contents for VJJT PanelBridge N5

  • Page 1 www.v j j t.com Mbps PanelBridge 5GHz lndoor/Outdoor 20dBi CPE real throughput 160Mbps+ Default IP:192.168.1.88 username:v j j t password:v j j t...
  • Page 2: Package Contents

    Introduction Thank you for purchasing the VJJT networks PanelBridge 5G20. This Quick Start Guide will let you know the installation of the PB-5G20 and packing information. ·Package Contents Power Cord 1(Qty.) PB-5G20 Passive PoE Adapter Pole Mounting Straps 1(Qty.) 1(Qty.) 2(Qty.)
  • Page 3: Led Explanation

    LED Explanation Power Main Secondary Wireless Signal Power LED On: The power on. Main and Secondary LED On: A device is connected to this port, but there is no activity. Flashing: A device is connected to this port, and is active. Wireless Signal LED AP/AP Router mode: All four LEDs remain solid.
  • Page 4: Connection And Installation

    Please connect and install the device as shown in the figure below. PanelBridge 5GHz 300Mbps 20dBi Outdoor CPE Model: PB-5G20 Power: 24V 0.5A Default Settings: IP: 192.168.1.88 Usemame: vjjt Password: vjjt Secondar y Power Main Secondary Wireless Signal Ethernet cable length up to 60m Connect to a computer, router or switch.
  • Page 5 3. Launch your web browser. Type https://192.168.1.88 in the address field .Press enter (PC) or return (Mac). 4. The login screen will appear. Enter vjjt in the Username and Password fields. Select your Country and Language. You must agree to the Terms of Use to use the product. Click Login.
  • Page 6 ① Shielded CAT5e (or above) Cable with Ground Wire ② Grounding Terminal and Cable PanelBridge 5GHz 300Mbps 20dBi Outdoor CPE Model: PB-5G20 Power: 24V 0.5A Default Settings: IP: 192.168.1.88 Usemame: vjjt Password: vjjt Power Main Secondary Wireless Signal Grounding Cable Grounding Terminal...
