Summary of Contents for Bogart Engineering SC-2030
- Page 1 TM-2030 Charging. Connected. Flashing = Overload System Volts: 12V-down 24V-up Battery Type: AGM-down Flood-up...
- Page 2 SC-2030 Installation Crossover Modular Cable to SC-2030 or serial data Solar panels connection “12” or “24 volt” types (36 or 72 cells per panel) SC-2030 Negative from all loads and -30 amps max charging sources charging current connect to shunt...
- Page 3 Programming Instructions for the TM-2030: http://www.bogartengineering.com/wp-content/uploads/docs/EnterP1Data.pdf The SC-2030 will operate as a standalone charger with minimal function unless connected to the TM-2030. Visit our website for more information P8-P22 are accessible only when Program P7 The following settings apply only when using the SC-2030 Solar Charge controller with the TriMetric monitor.
