GEIGER GF0.10 Operating Instructions

Operating Instructions GF0.10
The hand-held transmitter GF0.10 has been specially designed for the operation of one or several simultaneously
moving awnings (retracting enabled via key
The control keys and
sun-automatic ( = sun-automatic "OFF",
The required coding is realised by means of the coding switch (DIP switch) that exists inside the hand-held
transmitter.
In the event the LED doesn't light up if actuating one of the control keys, the battery needs to be replaced.
Battery: 12 V, type A23. The following battery types can be used for replacement: 23A, VA23A, MS21 or MN21.
Spent batteries must be disposed of in compliance with the relevant national rules currently operative and in force.
Transmit frequency: 433.92 MHz
To make a code setting or to replace the battery, please loosen the crosshead screws (Phillips screws) that exist at
the bottom of the hand-held transmitter by means of a cross-slot screwdriver (size PZ 0, ISO 8764) and separate
the two half-shells from each other. Use the DIP switches No. 1 to 6 in order to set the desired personal coding.
The transmitter complies with the relevant technical regulations enacted by the European Community. It bears the
CE mark and is authorised for use in all EU member states and in Switzerland without any need of prior registra-
tion. To learn more about the EC Declaration of Conformity pertaining to this hand-held transmitter, please visit our
website at: www.geiger-antriebstechnik.de.
Gerhard Geiger GmbH & Co. KG • Schleifmühle 6 • D-74321 Bietigheim-Bissingen • Telephone +49 (0) 71 42/9 38-0
Fax +49 (0) 71 42/9 38-230 • info@geiger-antriebstechnik.de • www.geiger-antriebstechnik.de
, extending via key
have been equipped with a special function for the activation or deactivation of the
= sun-automatic "ON").
a. E xtending
b. R etracting
c. S un-automatic "ON"
d. S un-automatic "OFF"
1 2 3 4
+
0
-

Individual coding

).
5 6 7 8 9
Allocation of
sensor signal
