- Page 1 AxV60 / AxV80 I N S T A L L A T I O N G U I D E...
-
Page 2: Call Customer Service
CALL CUSTOMER SERVICE 1.888.213.5015 MON-FRI 8AM-6PM EST Visit us online for product support, guides and videos www.leonspeakers.com/support AXIS SERIES: AxV60/AxV80 SETUP GUIDE... - Page 3 EQ switch to tailor the sound to the room surfaces, placement or desired balance. Available with 6” or 8” drivers and 1” Tetron-woven tweeters • Can be custom painted by Leon to match any wall color or paint code • Available with either round or square magnetic grills •...
-
Page 4: Technical Specifications
FREQ. RESPONSE 45Hz-22kHz IMPEDANCE 6Ω AxV80 11.2” 3.9” 9.875” 10.75” RECOMMENDED CUTOUT COMPONENTS 8” midrange woofer; 1” Tetron-woven tweeter POWER HANDLING 50W RMS / 150W Peak @ 1w/1m SENSITIVITY 90 dB FREQ. RESPONSE 40Hz-22kHz 6Ω IMPEDANCE AXIS SERIES: AxV60/AxV80 SETUP GUIDE... -
Page 5: Installation
INSTALLATION CHOOSING THE BEST PLACE TO INSTALL YOUR SPEAKERS Since speaker installation is permanent and the furniture placement may not be, you should first determine the best long-term location for the speakers. Take into consideration a design that might accommodate future relocation of the furniture in the room and still provide well-balanced sound to the primary listening area. -
Page 6: Retrofit Installations
Run the speaker wire in the wall down to the amplifier/receiver location. Allow for a 3‘ service loop for removal and easy movement of equipment. Follow the ‘ALL INSTALLATIONS’ steps 1-4 on the following page. AXIS SERIES: AxV60/AxV80 SETUP GUIDE... -
Page 7: All Installations
Finally, replace the scrim cloth after painting to prevent the speaker components from showing through. Leon Speakers’ custom paint shop can also produce professional paint matched results. Consult your Leon Speakers sales representative for more information. - Page 8 715 W. Ellsworth Road Ann Arbor, Michigan 48108 | 1.888.213.5015 | www.leonspeakers.com...
