- Page 1 SUN FLUX USER MANUAL & INSTALLATION GUIDE OFF GRID / HYBRID SOLAR HOT WATER CONTROLLER...
- Page 2 6: Remove the protective cover from the terminal block on the base of the Sun Flux. 7: Connect the AC grid input wires to the AC grid input on the base of the Sun Flux in accordance with the instructions below terminal block.
- Page 3 10: Turn on PV solar power and AC grid power and commence operation and inspection. When the Sun Flux is powered up in solar mode the green led will be lit if the green led is not lit turn off the PV solar power immediately and check the polarity of the MC4 plugs from the PV solar array are correct.
- Page 4 Sun Flux functions 1: Green led lit when in solar mode. 2: Red led lit when in grid mode. 3: Negative MC4 input from the solar array. 4: Positive MC4 input from the solar array. 5: Terminal block for AC grid input and load output.
