Working Parameters and
Specifications
Maximum Inlet Pressure:
25 bar
Outlet Adjustable Pressure:
1.0 - 6 bar
Pre-set Pressure:
4 bar
Maximum Temperature:
70ºC
Test Port Size:
¼" BSP
Suitable Media:
Water
Compressed Air
Neutral non-adhesive liquids/gases
Spares
Product Code
Description
REDC315010:
Adj 1.0-6 bar PRV cartridge for ½" &
¾"MBSP valve
REDC315020:
Adj 1.0-6 bar PRV cartridge for
1"MBSP valve
REDC315030:
Adj 1.0-6 bar PRV cartridge for 1 ¼", 1
½" & 2"MBSP valve
REDC315035:
Pre-set 3.5 bar PRV cartridge for
28mm compression
Reliance Worldwide Corporation
(UK) Ltd
Worcester Road,
Evesham,
Worcester,
WR11 4RA,
UK
Tel: +44 (0)1386 712 400
Fax: +44 (0)1895 712 401
www.rwc.co.uk
Reliance Worldwide Corporation (UK) Ltd reserves the right to make changes to the product which may
affect the accuracy of information contained in this leaflet.
ZINS315010_002_07-15
Installation and Maintenance
Instructions
315i Pressure Reducing
Valves
Advertisement
Table of Contents
Related Manuals for RWC 315i
Summary of Contents for RWC 315i
-
Page 1: Specifications
Maximum Temperature: 70ºC Test Port Size: ¼" BSP (UK) Ltd Suitable Media: Water Worcester Road, Compressed Air 315i Pressure Reducing Neutral non-adhesive liquids/gases Evesham, Spares Valves Worcester, WR11 4RA, Tel: +44 (0)1386 712 400 Fax: +44 (0)1895 712 401 www.rwc.co.uk... - Page 2 ¼" pressure gauge to the pressure reducing test ports on the base of Install the 315i pressure reducing valve into your pipe work, valve cartridge into the valve. it can be installed in any orientation as long as the flow is...
